ESIE06-03
AC1, AC2, U, V, W, Connector
X11A, X12A, E1,
E2, HR1, HR2
FU1, FU2, FU3 Fuse
L Live
L1R Reactor
LEDA Pilot lamp
M1C Fan motor
M1F Fan motor
MRC/W, MRM10, Magnetic relay
MRM20
N Neutral
PCB1, PCB2 Printed circuit board
Part 1 – System Outline
PM1 Power module
Q1L Overload protector
R1T~R3T Thermistor
S2~S102 Connector
SA2 Surge arrester
Sheet metal Terminal strip fixed plate
SW1 Forced operation On/Off SW (SW1)
SW4 Local setting SW (SW4)
V2, V3, V5, V9, V100 Varistor
X1M, X2M Terminal strip
Y1E Electronic expansion valve coil
Y1R Reversing solenoid valve coil
Z1C~Z7C Ferrite core
Wiring Diagrams
1
3
4
5
1–49
