- Page 1 Operation manual Daikin Altherma 3 M EBLA09~16DAV3 EBLA09~16DAW1 EBLA09~16DA3V3 EBLA09~16DA3W1 EDLA09~16DAV3 EDLA09~16DAW1 Operation manual EDLA09~16DA3V3 English Daikin Altherma 3 M EDLA09~16DA3W1...
-
Page 2: Table Of Contents
Overview: Maintenance and service ......... 18 Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer. 8 Troubleshooting The original documentation is written in English. All other languages To display the help text in case of a malfunction....... 18 are translations. -
Page 3: User Safety Instructions
The appliance shall be stored so as to Cleaning and user maintenance prevent mechanical damage and in a SHALL NOT be made by children well-ventilated room without without supervision. continuously operating ignition sources EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 4: About The System
▪ Confirm the pin code and proceed. About the system User pin code The User pin code is 0000. Depending on the system layout, the system can: ▪ Heat up a space Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 5: Space Heating/Cooling
Additional zone – Heating [3.5] Additional zone > Heating WD curve Additional zone – Cooling [3.6] Additional zone > Cooling WD curve 2 Change the weather-dependent curve. EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 6: Domestic Hot Water
([C.3]: Operation > Tank), disinfection mode will remain active. However, if you turn it OFF while disinfection is running, an AH error occurs. Slot for WLAN cartridge USB connector Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... - Page 7 Slot for WLAN cartridge With the WLAN cartridge, the installer can connect the system to the internet. As user you can then control the system via the Daikin Residential Controller app. Note: This slot cannot be used for SD cards.
-
Page 8: Menu Structure: Overview User Settings
Only applicable for reversible models (**) Only accessible by installer (***) Only applicable when WLAN is installed INFORMATION Depending on the selected installer settings and unit type, settings will be visible/invisible. Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 9: Possible Screens: Overview
Go through the list of the main menu. Go to the main menu screen. Enable/disable breadcrumbs. Item Description a Domestic hot water Domestic hot water Measured tank temperature EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 10: Main Menu Screen
LAN (WLAN) is installed. gateway 5.3.2 Main menu screen Contains settings needed when configuring the Daikin Residential Starting from the home screen, press ( ) or turn ( ) the Controller app. left dial to open the main menu screen. From the main menu, you can access the different setpoint screens and submenus. -
Page 11: Detailed Screen With Values
Tank Space heating/cooling operation ON Space heating/cooling operation OFF 2 Set operation to On or Off. Reading out information To read out information 1 Go to [8]: Information. EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 12: Space Heating/Cooling Control
To restrict automatic changeover according to a schedule Conditions: You set the space operation mode to Automatic. 1 Go to [4.2]: Space heating/cooling > Operation mode schedule. 2 Select a month. Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 13: Domestic Hot Water Control
Powerful operation allows the domestic hot water to be heated by the backup heater or booster heater. Use this mode on days when there is more hot water usage than usual. EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 14: Schedule Screen: Example
In this example, Monday is the first day you programmed. Thus, the last programmed action is valid up to the first action of next Monday. Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 15: Weather-Dependent Curve
4 Confirm the changes. local circumstances such as climate and the insulation of the house, 5 Select Saturday. the curve can be adjusted by an installer or user. 6 Select Copy. EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 16: 2-Points Curve
Possible actions on this screen X1, X2 Examples of outdoor ambient temperature Go through the temperatures. Change the temperature. Go to the next temperature. Confirm changes and proceed. Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 17: Using Weather-Dependent Curves
It will take more time and energy to heat up/cool Additional zone – Cooling [3.6] Additional zone > down the room again. Cooling WD curve EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 18: Maintenance And Service
The appliance shall be stored so as to prevent mechanical damage and in a well-ventilated room without continuously operating ignition sources (example: open flames, an operating gas appliance or an operating electric heater). Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 19: Symptom: You Are Feeling Too Cold (Hot) In Your Living Room
▪ When Emergency is set to Automatic and a heat pump failure occurs, the backup heater automatically takes over the heat load, and the booster heater in the optional tank takes over the domestic hot water production. EBLA09~16DA + EDLA09~16DA Operation manual Daikin Altherma 3 M 4P620243-1B – 2021.02... -
Page 20: Disposal
Additional capacity step 2 [9.3.5] (if applicable) Main zone Emitter type [2.7] Control [2.9] Setpoint mode [2.4] Schedule [2.1] WD curve type [2.E] Additional zone (only if [4.4]=1, dual zone) Operation manual EBLA09~16DA + EDLA09~16DA Daikin Altherma 3 M 4P620243-1B – 2021.02... - Page 24 4P620243-1 B 0000000V 4P620243-1B 2021.02 Verantwortung für Energie und Umwelt...
