Removing Or Replacing A Line Module - HP Aruba 6400 Series Installation And Getting Started Manual

4. Loosen the screws securing the module you converted to Standby in step 3.
5. Open the locking module levers and pull the module out of its slot. Place the module in an antistatic bag
for protection from ESD damage.
6. If you do not plan to install another management module in the empty slot, then secure a management
module slot cover over the slot opening.

Removing or replacing a line module

NOTE: If you are exchanging one type of line module with a different type in the same slot, or
not replacing the module at all, reset the slot to the default configuration by using the no
module <SLOT-NUM> command. If you are exchanging a line module for another line module
of the same type, resetting the slot is not needed. In this case, the existing slot configuration is
retained.
Prerequisites
Have the replacement line module available and ready to install.
Procedure
1. If you are replacing a line module with another module of the same type, skip this step and go to step 3.
Otherwise, use the switch console to access the global configuration context in the switch CLI.
Switch(config)#
Chapter 9 Adding or replacing switch components
NOTE: After using the redundancy-switchover command, check the Active and Standby
LEDs on both modules to ensure that the Active/Standby conversion took place. If the
Standby management module was not available when the command was executed, the
conversion fails.
1
2
3
1
2
85
