Symbol Spectrum24 AP-4131 Product Reference Manual page 191

WLAP Itf MAC Addr
Itf State
Path Cost
Designated Root ID
Designated Cost
Designated WLAP ID A WLAP ID assigned by the Root AP .
Designated Itf ID
AP-4131 Access Point Product Reference Guide
– Select
– Select to automatically update this display every two seconds.
– Press ESC to return to the previous menu.
States the MAC address of the associated WLAP .
Identifies the state of the interface from:
• DIS - the interface is disabled
• LIS - the AP listens for information
• LRN - the AP learns the information
• FWD - the AP forwards data
• BLK - the AP blocks transmission.
An abstract unit added to the Root Path Cost field in
the Config BPDU received on this interface. The unit
represents a hop on the path to the Root AP .
An ID designated by the Root AP . APs in WLAP mode
negotiate the position of Root AP at power up. The
AP with the lowest Root ID, path and WLAP ID
becomes the Root AP . The Root ID and the WLAP ID
are -digit numbers. The first
Priority value and the remaining
the MAC address of the AP .
A path cost designated by the Root AP .
An Itf ID assigned by the Root AP .
at the status display to update the values manually.
Monitoring Statistics
digits represent the
digits represent
181
