AP 300
802.11a/b/g Access Port
Internal Antenna Model
Quick Reference Guide

Advertisement

Table of Contents
loading

Related Manuals for Symbol AP 300

Summary of Contents for Symbol AP 300

  • Page 1 AP 300 802.11a/b/g Access Port Internal Antenna Model Quick Reference Guide...
  • Page 2 Symbol Technologies, Inc. (Symbol). The material in this manual is subject to change without notice. Symbol reserves the right to make changes to any product to improve reliability, function, or design. No license is granted, either expressly or by implication, estoppels, or otherwise under any Symbol Technologies, Inc., intellectual property...

  • Page 3: Technical Specifications

    For optimal performance, the AP 300 provides two placement options: wall and ceiling. Wall mount slots fit onto two screws provided; marks on the AP 300 case guide placement of the screws. Clips on the back of the case fit onto a suspended ceiling T-bar.

  • Page 4: Radio Characteristics

    AP 300 Quick Reference Guide FINAL.Not for distribution. Radio Characteristics The AP 300 is an IEEE 802.11a/b/g-compliant device with the appropriate radio option configured. The table below shows the characteristics for each device compliance. Device Mbps Data Rate Utilizing Support Diversity 802.11a...
  • Page 5 • Slots for wall mounting • Clips for ceiling T-bar mounting The AP 300 has one RJ-45 connector for a 10/100 Ethernet port connecting to a wireless switch with a standard CAT-5 cable, straight through or cross-over, without any strain relief.

  • Page 6: Led Indicators

    802.11 MAC. All upper MAC functions and MAC management are controlled by the Wireless Switch. Motherboard firmware enables the AP 300 to boot after either a power up or a watchdog reset. After self-boot, the motherboard sends an “I am alive”...

  • Page 7: Installation Instructions

    Review site survey and network analysis reports to determine the location and mounting position for the AP 300. Wall Mounting In the procedure below, hang the AP 300 Access Port along its length or width using the slots on the bottom of the unit. Hardware •...

  • Page 8: Suspended Ceiling T-Bar Mount

    8. Verify the unit has power by observing that the LEDs are lit or flashing. Suspended Ceiling T-Bar Mount In this procedure, hold and twist the AP 300 on a T-bar of a suspended ceiling grid, clicking the case into place. Hardware •...
  • Page 9 FINAL.Not for distribution. 6. Push the back of the case onto the bottom of the T-bar. 7. Rotate the case 45 degrees clockwise. The clips click as they fasten to the T-bar. 8. Verify the unit has power by observing the LEDs.

  • Page 10: Customer Support

    AP 300 Quick Reference Guide FINAL.Not for distribution. Customer Support Symbol Technologies provides its customers with prompt and accurate customer support. Use the Symbol Support Center as the primary contact for any technical problem, question or support issue involving Symbol products.

  • Page 11: Web Support Sites

    Web Support Sites MySymbolCare http://www.symbol.com/services/msc Symbol Services Homepage http://symbol.com/services Symbol Software Updates http://symbol.com/services/downloads Symbol Developer Program http://software.symbol.com/devzone Symbol Knowledge Base http://kb.symbol.com/register.asp Additional Information Obtain additional information by contacting Symbol at: • 1-800-722-6234, inside North America • +1-631-738-5200, in/outside North America • http://www.symbol.com/...

  • Page 12: Legal Information

    AP 300 Quick Reference Guide FINAL.Not for distribution. Legal Information Regulatory All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment.

  • Page 13: Remote And Standalone Antenna Configurations

    FINAL.Not for distribution. FCC RF Exposure Guidelines Safety Information Caution: The device complies with internationally recognized standards covering Specific Absorption Rate (SAR) related to human exposure to electromagnetic fields from radio devices. It is advisable to use the device only in the normal operating position. Remote and Standalone Antenna Configurations.

  • Page 14: Radio Transmitters

    2.460GHz to 2.4835 GHz. • Italy requires a user license for outside usage. The use of 5GHz RLAN's has varying restrictions for use within the EEA; please refer to the Symbol Declaration of Conformity (DoC) for details at http:// www2.symbol.com/doc/ Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with...
