Accessories
All the accessories in Table 7 include mounting
hardware; contact the nearest Johnson Controls®
representative to order any of these parts.
Note: Review the technical specifications of the
optional accessories prior to their use in an application.
Table 7: Accessories (Order Separately)
Code Number Description
SEN-600-1 Remote Indoor Air Temperature Sensor
SEN-600-4 Remote Indoor Air Temperature Sensor with Occupancy Override and LED
1 Duct Mount Air Temperature Sensor
TE-6361M-1
1 Strap-on Temperature Sensor
TE-636S-1
1. Additional TE-636xx-x Series 10k Type II Thermistor Sensors are available; refer to the TE-6300 Series Temperature
Sensors Product Bulletin (LIT-216320) for more details.
Table 8: Troubleshooting Details (Part 1 of 2)
Symptom Cause
No display on the Absent or incorrect
thermostat supply voltage
Overloaded power
transformer
Keyboard menu Keyboard locked
does not access all
functions
Temperature Temporary setpoint
setpoints revert to active for a period of
original value after time set by
a certain time parameter
TOccTime
Thermostat does Wrong mode
not call for heating selected
Thermostat in
Unoccupied mode
Anticycle delay
active
Heating setpoint is
satisfied
Heating lockout
attained
Wiring error
TEC22x4-3 L W ® Networked Multi-Stage Economizer Thermostats Installation Instructions
ON ORKS

Repair Information

If the TEC22x4-3 thermostat fails to operate within its
specifications, see Table 8 for troubleshooting details
and Table 9 for display messaging. For a replacement
thermostat, contact the nearest Johnson Controls
representative.
Solution(s)
Check that the power supply voltage between RC and C is in the range of
19 to 30 VAC.
Check for tripped fuse or circuit breaker.
Verify that the transformer used is powerful enough (enough VAs) to supply all
controlled devices including the thermostat.
1. Use the Installer Configuration menu to change the Lockout level to 0 or 1.
2. Change the nciGenOpts Byte 27(28) lockout value to 0 or 1.
To do a permanent change to the setpoints you must enter the menu
RoomTemp Set and modify the setpoints at desired temperature.
Select heating mode.
Select Override to force the thermostat Occupied heating setpoint.
Wait — the anticycling period must end before the equipment can start.
Raise the Heating setpoint.
Mode is locked out based on outside air temperature.
Change configuration parameter H Lock to value 120°F (49°C) to by-pass
lockout.
Start the Fan by forcing the Fan ON mode.
Put a jumper across terminals RH and W1. The heating should come ON. If it
does not, verify wiring and check if a jumper is required between RC and RH.
