2. Press the UP/DOWN arrow keys to locate the
desired system mode. Press the YES key to select
the desired system mode.
3. Press the YES key to return to the Status Display
Menu or press the NO key to return to the system
mode selection menu.

Selecting the Fan Mode

The thermostat has three fan mode settings:
• On Fan Mode (on): Energizes the fan all the time
for both occupied and unoccupied states, even if
the system mode is set to off.
• Automatic Fan Mode (auto): Energizes the fan
only on a call for heating or cooling, for both
occupied and unoccupied states.
• Smart Fan Mode (smart): Energizes the fan all
the time for occupied states, and only on a call for
heating or cooling in unoccupied states. This is the
default setting.
To select the fan mode while in the Main User Menu:
1. Press the NO key to all prompts until the fan mode
prompt appears on the display. Press the YES key
to set the fan mode.
2. Press the UP/DOWN arrow keys to locate the
desired fan mode. Press the YES key to select the
desired fan mode.
3. Press the YES key to return to the Status Display
Menu or press the NO key to return to the fan
mode selection menu.
Selecting Schedule (TEC2264-3 Only)
Programming the Daily Schedule – Two-Event
The schedule-setting menu is used to enter the
occupied or unoccupied states for each day of the
week. The schedule-setting menu reflects either a
two- or a four-event schedule per day, based on what
was selected in the 2/4event parameter during the
configuration process. If the schedule-setting menu
does not reflect a two-event schedule, select two
events in the 2/4event parameter of the Installer
Configuration Menu.
When changing the time, press the UP/DOWN arrow
keys once to change the time in 1-minute increments;
press and hold down the keys to change the time in
30-minute increments.
Note: Programming one of the digital inputs to remote
NSB disables the menu.
12 TEC22x4-3 L W
ON
® Networked Multi-Stage Economizer Thermostats Installation Instructions
ORKS
To set the time schedule for a two-event schedule,
follow the steps in Table 4. See Table 6, Events 1
and 2, for an example of a two-event office schedule.
Table 4: Programming the Daily Schedule –
Two-Event (Part 1 of 2)
Thermostat Description
Display
Press the MENU key while in the
Status Display Menu to enter the
RoomTemp
Main User Menu.
75.0 ° F
Press the NO key to all prompts until
the schedule set prompt appears on
Schedule
the display. Press the YES key to
set? Y/N
enter the scheduling menu.
Press the YES key to set the
schedule for Monday or press the NO
Monday
key to advance to Tuesday.
set? Y/N
Press the YES key to set the
occupied start time for Monday or
Occupied
press the NO key to advance to
day? Y/N
Tuesday. Selecting NO will leave the
thermostat in the unoccupied state
for the entire day.
Press the UP/DOWN arrow keys to
set the occupied start time. Press the
Occupied
YES key to enter the time.
12:00 AM
Press the UP/DOWN arrow keys to
set the unoccupied start time. Press
Unoccup
the YES key to enter the time.
12:00 AM
Press the YES key to set the
schedule for Tuesday or press the
Tuesday
NO key to advance to Wednesday.
set? Y/N
Press the YES key to copy the
schedule from the previous day.
Copy Y/N
Press the NO key to set a different
previous
schedule.
