Table 4: Programming the Daily Schedule –
Two-Event (Part 2 of 2)
Thermostat Description
Display
If the YES key was pressed, the next
prompt is for Wednesday. Repeat the
Wednesda
procedure for the rest of the days of
set? Y/N
the week.
After setting the schedule for all the
days of the week, following the last
Exit?
entry for Sunday, press the YES key
Y/N
to return to the Status Display Menu
or press the NO key to start again at
Monday.
Programming the Daily Schedule – Four-Event
The schedule-setting menu is used to enter the
occupied and unoccupied states for each day of the
week. The schedule-setting menu reflects either a
two- or four-event schedule per day, based on what
was selected in the 2/4event parameter during the
configuration process. If the schedule-setting menu
does not reflect a four-event schedule, select four
events in the 2/4event parameter of the Installer
Configuration Menu.
When changing the time, press the UP/DOWN arrow
keys once to change the time in 1-minute increments;
press and hold down the keys to change the time in
30-minute increments.
Note: Programming one of the digital inputs to remote
NSB disables the menu.
To set the time schedule for a four-event schedule,
follow the steps in Table 5. See Table 6 for an example
of a four-event office schedule.
Table 5: Programming the Daily Schedule –
Four-Event (Part 1 of 2)
Thermostat Description
Display
Press the MENU key from the Status
Display Menu to enter the Main User
RoomTemp
Menu.
75.0 ° F
Press the NO key to all prompts until
the schedule set prompt appears on
Schedule
the display. Press the YES key to
set? Y/N
enter the scheduling menu.
TEC22x4-3 L W ® Networked Multi-Stage Economizer Thermostats Installation Instructions
ON ORKS
Table 5: Programming the Daily Schedule –
Four-Event (Part 2 of 2)
Thermostat Description
Display
Press the YES key to set the
schedule for Monday or press the NO
Monday
key to advance to Tuesday.
set? Y/N
Press the YES key to set the
occupied start time for Monday or
Occupied
press the NO key to advance to
day? Y/N
Tuesday. Selecting NO will leave the
thermostat in the unoccupied state
for the entire day.
Press the UP/DOWN arrow keys to
set the first occupied start time. Press
Occupied
the YES key to enter the time.
12:00 AM
Press the UP/DOWN arrow keys to
set the first unoccupied start time.
Unoccup
Press the YES key to enter the time.
12:00 AM
Press the UP/DOWN arrow keys to
set the second occupied start time.
Occupie2
Press the YES key to enter the time.
12:00 AM
Press the UP/DOWN arrow keys to
set the second unoccupied start time.
Unoccup2
Press the YES key to enter the time.
12:00 AM
Press the YES key to set the
schedule for Tuesday or press the
Tuesday
NO key to advance to Wednesday.
set? Y/N
Press the YES key to copy the
schedule from the previous day.
Copy Y/N
Press the NO key to set a different
previous
schedule.
If the YES key was pressed, the next
prompt is for Wednesday. Repeat the
Wednesda
procedure for all days of the week.
set? Y/N
After setting the schedule for all the
days of the week, following the last
Exit?
entry for Sunday, press the YES key
Y/N
to return to the Status Display Menu
or press the NO key to start again at
Monday.
13
