Setting Limit Overrun

WARNING:
reversing devices, including photocells and sensing edges or
reversing edges. Therefore, any externally connected devices will
be disabled during that portion of the door travel controlled by the
Limit Overrun function.
The Down Limit Overrun function should be used to close the door
no more than the final 2".
AVERTISSEMENT:
dépassement de limite annulera les dispositifs de renversement
externes, y compris les cellules photoélectriques et des systèmes
de détection ou d'inversion aux bords. En conséquence, tous les
dispositifs externes connectés seront désactivés pendant la partie
de la course de la porte qui est contrôlée par la fonction de
dépassement de limite.
La fonction de dépassement de limite inférieure doit être utilisée
pour fermer la porte uniquement aux derniers 5 cm.
A) The Limit Overrun setting is a matter of trial and error. The goal is to adjust the Limit
Overrun until an appropriate seal is obtained between the bottom edge of the door
and the floor.
B) The Limit Overrun setting can be varied between 0 and 9. 0 - disables the Limit
Overrun so that the door stops at the down limit switch setting. 9 - causes the greatest
amount of door travel beyond the limit switch setting. Door should close gently with
light tension on door cables,or minimal stacking on rolling steel slats.
1) Press CAL-RUN to enter calibration mode
2) Press scroll (DN) until the display reads "LIMIT OVERRUN >(0-9)." Fig. 9.
The Limit Overrun will override external
La fonction de
www.geniecompany.com
3) Press SET/CLEAR until the display reads the desired value.
4) Press the OPEN key to open the door a few feet,then release
5) Press the CLOSE key to close the door and hold until the operator stops.
6) Check the door seal and repeat steps 3-5 until the appropriate
seal is obtained between the door and the floor.
CAUTION:
If proper seal cannot be obtained at a
setting of 9, Reset the Limit Overrun back to 0 and reset the
Down Limit position as described on 6.4. Then adjust the Limit
Overrun as instructed above.
ATTENTION:
ne peut être obtenue à un réglage de 9, réinitialiser le
dépassement de limite à 0 puis la position de déplacement de
la limite inférieure selon les instructions de la page 6.4. Régler
ensuite le dépassement de limite tel qu'indiqué ci-dessus.
7) Press CAL-RUN to return to Run mode.
LIMIT OVERRUN #
CAL
RUN
Figure 9
Si une adhésion appropriée
OPEN
CLOSE
STOP
SET
SCROLL
CLEAR
SCROLL
04-14 6.5
