TITLE PDL GX Internal Product Specification
MODEL PDL GX

4.6 Radio Specification

RF radiated field strength
RF Channel Spacing
Channel Bandwidth
Receive IF Frequency
Operating Temperature Range
Handset Transmission Frequency
Base Transmission Frequency
Transmitter Frequency Stability
Receiver Noise Figure
Sensitivity for 30dB SINAD
Image Rejection (RF)
Adjacent Channel Rejection
Receiver Muting Level

4.6.1 Frequency Allocation

The RF channels are allocated in fixed pairs as indicated in the tables below. The duplex frequency is
maintained at a fixed 22.75MHz for all 10 channels.

4.6.2 Base Unit Frequencies

Channel #
1
2
3
4
5
6
7
8
9
10

4.6.3 Handset Unit Frequencies

Channel #
1
2
3
4
5
6
7
8
9
10
Reference: PRC 00DM
This document is proprietary to V
Specifications are preliminary and are subject to change without notice.
E
NGINEERING
Transmit Frequency Receive Frequency
902.30 MHz 925.05 MHz
902.60 MHz 925.35 MHz
902.90 MHz 925.65 MHz
903.20 MHz 925.95 MHz
903.50 MHz 926.25 MHz
903.80 MHz 926.55 MHz
904.10 MHz 926.85 MHz
904.40 MHz 927.15 MHz
904.70 MHz 927.45 MHz
905.00 MHz 927.75 MHz
Transmit Frequency Receive Frequency
925.05 MHz 902.30 MHz
925.35 MHz 902.60 MHz
925.65 MHz 902.90 MHz
925.95 MHz 903.20 MHz
926.25 MHz 903.50 MHz
926.55 MHz 903.80 MHz
926.85 MHz 904.10 MHz
927.15 MHz 904.40 MHz
927.45 MHz 904.70 MHz
927.75 MHz 905.00 MHz
Revision: 3.0
E C L
TECH NGINEERING ANADA
C L
ANADA
<50 mV/meter @ 3m
300 kHz
150 kHz (20dB bandwidth)
10.7MHz
0 to +50°C
925.05 - 927.75 MHz
902.3 - 905.0 MHz
±5 kHz, 0 to +50°C
< 5.5dB
< -106 dBm at duplexer
> 60 dB
> 55 dB
Between -109 dBm and -107 dBm
Rx LO Frequency
914.35 MHz
914.65 MHz
914.95 MHz
915.25 MHz
915.55 MHz
915.85 MHz
916.15 MHz
916.45 MHz
916.75 MHz
917.05 MHz
Rx LO Frequency
913.00 MHz
913.30 MHz
913.60 MHz
913.90 MHz
914.20 MHz
914.50 MHz
914.80 MHz
915.10 MHz
915.40 MHz
915.70 MHz
.
