TITLE PDL GX Internal Product Specification
MODEL PDL GX

4.4 Telephone Line Interface Specification

Specifications marked with * are guaranteed at the nominal testing temperature and voltage on all units
with the use of automated production test equipment (ATE).
Parameter
* DTMF Frequency Tolerance
* DTMF Low Group Tone Level
* DTMF High Group Tone Level
DTMF Combined Tone Level
DTMF High Group Pre-emphasis (Twist)
Pulse Dialing Break Duration
Pulse Dialing Make Duration
Pulse Dialing Rate
Ring Detection Frequency
Ring Response Voltage
Ring No-Response Voltage
Notes:
1. Measured across a 900Ω terminating impedance
2. The ringer must ring with signals within this range
3. Measured with a frequency of 20Hz
4. The ringer must not ring with signals within this range
Reference: PRC 00DM
