CDM-600L Satellite Modem
Front Panel Operation
6.3.3.6
INFO: CLOCKS
CLOCKS: TX=INT(SCT) RX=RX-SAT
BUFFER-SIZE=00016
The TX Clock, RX Clock, REF Clock, and Buffer information is displayed.
6.3.3.7
INFO: EDMAC
EDMAC FUNCTION= ON
EDMAC MODE= MASTER
This screen shows if EDMAC is enabled or not. If it is enabled, the EDMAC Mode and
Address are shown.
6.3.3.8
INFO: DROP TYPE
DROP TYPE=
E1-CCS
This screen shows the Drop Type. Pressing ENTER takes the user back to the previous
menu.
6.3.3.9
INFO: INSERT TYPE
INSERT TYPE=
E1-CCS
This screen shows the Insert Type. Pressing ENTER takes the user back to the previous
menu.
EDMAC ADDR= 0020
CH:1
TS:01
CH:1
TS:01
6–31
MN/CDM600L.IOM
REF=INT
Revision 0
