CDM-600L Satellite Modem
Preface
Reporting Comments or Suggestions Concerning this Manual
Comments and suggestions regarding the content and design of this manual will be
appreciated. To submit comments, please contact the Comtech EF Data Technical
Publications Department: techpub@comtechefdata.com
Electrical Safety
The CDM-600L Modem has been shown to comply with the following safety standard:
The equipment is rated for operation over the range 100 - 240 volts AC. It has a
maximum power consumption of 290 watts, and draws a maximum of 2.9 mA.
IMPORTANT
Fuses
The CDM-600L is fitted with two fuses - one each for line and neutral connections.
These are contained within the body of the IEC power inlet connector, behind a small
plastic flap.
•
For 115 and 230 volt AC operation, use T3, 15A, T0.75A, 20mm fuses.
FOR CONTINUED OPERATOR SAFETY, ALWAYS REPLACE THE FUSES
WITH THE CORRECT TYPE AND RATING.
Environmental
The CDM-600L must not be operated in an environment where the unit is exposed to
extremes of temperature outside the ambient range 0 to 50°C (32° to 122°F),
precipitation, condensation, or humid atmospheres above 95% RH, altitudes (un-
pressurised) greater than 2000 metres, excessive dust or vibration, flammable gases,
corrosive or explosive atmospheres.
Operation in vehicles or other transportable installations that are equipped to provide a
stable environment is permitted. If such vehicles do not provide a stable environment,
safety of the equipment to EN60950 may not be guaranteed.
•
EN 60950: Safety of Information Technology Equipment, including
electrical business machines
The user should observe the following instructions:
xi
Revision 0
MN/CDM600.IOM
