CDM-600L Satellite Modem
Front Panel Operation
CONFIG: CLOCKS: EXTERNAL-CLOCK
EXTERNAL CLOCK= 02048.000 kHz
EXT CLK TYPE= UNBAL
To edit the EXT-REF CLOCK, select the digit to be edited using the [←] [→] arrow
keys. Edit the value of the digit using the [↑] [↓] arrow keys. Press ENTER.
6.3.1.6
CONFIG: DROP & INSERT
IMPORTANT
DRP-TYPE= T1-D4
INS-TYPE= T1-D4
sing the [←] [→] arrow keys, select one of the five parameters on the screen.
U
Note that Drop and Insert operation is a FAST option. Selecting LOOP will tie Drop
Data Out (DDO) to Insert Data Input (IDI) without the user having to externally connect
cables to these ports.
The Drop-Type and Insert-Type and Loop (Y/N) are edited on this screen using the [↑]
[↓] arrow keys. The Drop & Insert-Types are:
To edit the Channel Timeslots (CHAN/TS) for either Drop or Insert, press ENTER and
another screen will be shown:
Drop and Insert is discussed in the Chapter "Clock modes and Drop
and Insert (D&I)" later in this manual.
CHAN/TS
CHAN/TS
•
T1 – D4
•
T1 – ESF
•
E1 – CCS
•
E1 – CAS
(UNBAL,BAL)
LOOP=Y (Y/N)
6–19
Revision 0
MN/CDM600L.IOM
