How to Use Your Spacing Diagram
Your Spacing Diagram will indicate the following important dimensions:
1
ROW SPACING (Distance between Hook rows, along corrugation)
COLUMN SPACING (Dist. between Hook columns, across corrugation)
PANEL SPACING (Distance between panel columns)
2
Record the above numbers and do not confuse them.
xxx
Figure 2 - Sample Spacing Diagram
xxx
xxx
7
