Preparing for Installation
Ensure the surface of the roof is clear of debris and obstacles that may impair
1
the installation of the system or the performance and safety of the installation
team.
Check and count that all parts and their desired quantities have arrived in the
2
proper fashion.
How to Use Your Layout Diagram
Note the following items on your project specific Layout Diagram:
1
2
From your layout, use the N/S and E/W dimensions at a corner of your roof
as the ORIGIN (i.e. the beginning) of your installation.
NORTH ARROW
ARRAY NUMBERS
DIMENSIONS
ROOF STRUCTURES
Figure 1 - Sample Layout Diagram
LEGEND
SUPPORTS
6
