IMPORTANT
The hook profiles and hanger bolts must be
spaced according to the engineering drawings and
never at a greater spacing than as indicated.
Please refer to Figure 7 on the following page to
see the sample engineering drawing and specified
dimensions.
Figure 5 - Hook Orientation Option 1
Figure 6 - Hook Orientation Option 2
10
