TI00076D/06/EN/13.15
71231024
Easy-to-clean flowmeter with self-drainable single-tube system & extended
transmitter functionality
Application
• Measuring principle operates independently of physical fluid
properties such as viscosity or density
• Dedicated for applications requiring optimal cleanability
under hygienic conditions
Device properties
• Large range of hygienic process connections
• 3A and EHEDG conform
• Fast recovery from CIP/SIP
• Device in compact or remote version
Promass 83
• 4-line backlit display with touch control
• HART, PROFIBUS PA/DP, Modbus RS485, FF, EtherNet/IP
Products
Technical Information
Proline Promass 80S, 83S
Coriolis flowmeter
Solutions
Your benefits
• Reduced installation costs – fully self-drainable tube design
enables compact horizontal mounting
• Fewer process measuring points – multivariable
measurement (flow, density, temperature)
• Space-saving installation – no in/outlet run needs
Promass 83
• Quality – software for filling & dosing, density &
concentration, advanced diagnostics
• Flexible data transfer options – numerous communication
types
• Automatic recovery of data for servicing
Services
Advertisement
Chapters
Table of Contents
Related Manuals for Endress+Hauser Proline Promass 80S
Summary of Contents for Endress+Hauser Proline Promass 80S
-
Page 1: Technical Information
Products Solutions Services TI00076D/06/EN/13.15 71231024 Technical Information Proline Promass 80S, 83S Coriolis flowmeter Easy-to-clean flowmeter with self-drainable single-tube system & extended transmitter functionality Application Your benefits • Measuring principle operates independently of physical fluid • Reduced installation costs – fully self-drainable tube design... -
Page 2: Table Of Contents
Proline Promass 80S, 83S Table of contents Function and system design ..... .3 Medium density ........19 Fluid pressure range (nominal pressure) . -
Page 3: Function And System Design
Proline Promass 80S, 83S Function and system design Measuring principle The measuring principle is based on the controlled generation of Coriolis forces. These forces are always present when both translational and rotational movements are superimposed. = 2 · Δm (v · ω) = Coriolis force Δm = moving mass... -
Page 4: Measuring System
Proline Promass 80S, 83S Measuring system The measuring system consists of a transmitter and a sensor. Two versions are available: • Compact version: transmitter and sensor form a mechanical unit. • Remote version: transmitter and sensor are mounted physically separate from one another. -
Page 5: Operable Flow Range
Proline Promass 80S, 83S Measuring ranges for gases The full scale values depend on the density of the gas. Use the formula below to calculate the full scale values: = · ρ / x [kg/m max(G) max(F) ... -
Page 6: Output
Proline Promass 80S, 83S Output Output signal Promass 80 Current output: Active/passive selectable, galvanically isolated, time constant selectable (0.05 to 100 s), full scale value selectable, temperature coefficient: typically 0.005% o.r./°C, resolution: 0.5 μA • Active: 0/4 to 20 mA, R <... - Page 7 Proline Promass 80S, 83S • Output data: Mass flow, Volume flow, Corrected volume flow, Density, Reference density, Temperature, Totalizers 1 to 3 • Input data: Positive zero return (ON/OFF), Zero point adjustment, Measuring mode, Totalizer control • Bus address can be configured via miniature switches or via the local display (optional) •...
-
Page 8: Signal On Alarm
Proline Promass 80S, 83S Signal on alarm Current output Failsafe mode selectable (e.g. in accordance with NAMUR Recommendation NE 43) Pulse/frequency output Failsafe mode selectable Status output (Promass 80) Nonconductive in the event of a fault or if the power supply fails... - Page 9 Proline Promass 80S, 83S Promass 83 The inputs and outputs on the communication board can be either permanently assigned (fixed) or variable (flexible), depending on the version ordered (see table). Replacements for modules which are defective or which have to be replaced can be ordered as accessories.
-
Page 10: Supply Voltage
Proline Promass 80S, 83S Supply voltage 85 to 260 V AC, 45 to 65 Hz 20 to 55 V AC, 45 to 65 Hz 16 to 62 V DC Power consumption AC: <15 VA (including sensor) DC: <15 W (including sensor) Switch-on current: •... -
Page 11: Electrical Connection
Proline Promass 80S, 83S Electrical connection b d/(g) HART* PROFIBUS PA* FOUNDATION Fieldbus* PA(–)/FF(–) – 27 PA(+)/FF(+) + 26 – – 25 + 24 – – 23 + 22 – – 21 + 20 N (L-) 2 N (L-) 2... -
Page 12: Electrical Connection Remote Version
Proline Promass 80S, 83S Electrical connection Remote version S1 S1 S2 S2 GND TM TM TT TT 9 10 11 12 41 42 9 10 11 12 41 42 S1 S1 S2 S2 GND TM TM TT TT a0003681 Connecting the remote version Wall-mount housing: non-hazardous area and ATEX II3G, zone 2 →... -
Page 13: Maximum Measured Error
Proline Promass 80S, 83S Maximum measured error Design fundamentals → 15 o.r. = of reading; 1 g/cm = 1 kg/l; T = fluid temperature Base accuracy Mass flow and volume flow (liquids) Promass 83S: • ±0.10% o.r. Promass 80S: •... -
Page 14: Repeatability
Proline Promass 80S, 83S US units 1:10 1:20 1:50 1:100 1:500 [in] [lb/min] [lb/min] [lb/min] [lb/min] [lb/min] [lb/min] ³⁄₈" 73.50 7.350 3.675 1.470 0.735 0.147 ½" 238.9 23.89 11.95 4.778 2.389 0.478 1" 661.5 66.15 33.08 13.23 6.615 1.323 1½"... -
Page 15: Influence Of Fluid Pressure
Proline Promass 80S, 83S Influence of fluid pressure The table below shows the effect on accuracy of mass flow due to a difference between calibration pressure and process pressure. Promass S [mm] [in] [% o.r./bar] ³⁄₈" –0.002 ½" –0.006 1"... -
Page 16: Installation
Proline Promass 80S, 83S Installation Mounting location Entrained air or gas bubbles in the measuring tube can result in an increase in measuring errors. Therefore, avoid the following mounting locations in the pipe installation: • Highest point of a pipeline. Risk of air accumulating. -
Page 17: Orientation
Proline Promass 80S, 83S Orientation Make sure that the direction of the arrow on the nameplate of the sensor matches the direction of flow (direction of fluid flow through the pipe. Vertical (Fig. V) Recommended orientation with upward direction of flow. When fluid is not flowing, entrained solids will sink down and gases will rise away from the measuring tube. -
Page 18: Installation Instructions
Proline Promass 80S, 83S Installation instructions Note the following points: • No special measures such as supports are necessary. External forces are absorbed by the construction of the instrument, for example the secondary containment. • The high oscillation frequency of the measuring tubes ensures that the correct operation of the measuring system is not influenced by pipe vibrations. -
Page 19: Environment
Proline Promass 80S, 83S Environment Ambient temperature range Sensor, transmitter: • Standard: –20 to +60 °C (–4 to +140 °F) • Optional: –40 to +60 °C (–40 to +140 °F) • Install the device at a shady location. Avoid direct sunlight, particularly in warm climatic regions. -
Page 20: Pressure-Temperature Rating
Proline Promass 80S, 83S Note! In case a danger of measuring tube failure exists due to process characteristics, e.g. with corrosive process fluids, we recommend the use of sensors whose secondary containment is equipped with special pressure monitoring connections (ordering option). With the help of these connections, fluid collected in the secondary containment in the event of tube failure can be bled off. - Page 21 Proline Promass 80S, 83S JIS B2220 flange Flange material: 1.4404 (316/316L) [psi] [bar] [°C] [°F] A0020971-EN DIN 11851 thread Connection material: 1.4435 (316L) [psi] [bar] DN 8…40 DN 50 [°C] [°F] A0021009-EN DIN 11851 allows for applications up to +140 °C (+284 °F) if suitable sealing materials are used. Please take this into account when selecting seals and counterparts as these components can limit the pressure and temperature range.
- Page 22 Proline Promass 80S, 83S DIN 11864-2A flange Flange material: 1.4435 (316L) [psi] [bar] DN 8...40 DN 50 [°C] [°F] A0020968-EN SMS 1145 thread Connection material: 1.4435 (316L) [psi] [bar] [°C] [°F] A0020918-EN SMS 1145 allows for applications up to 6 bar (87 psi) if suitable sealing materials are used. Please take this into account when selecting seals and counterparts as these components can limit the pressure and temperature range.
-
Page 23: Limiting Flow
– Relative magnetic permeability μ ≥ 300 – Plate thickness d ≥ 0.35 mm (0.014") • Information on permitted temperature ranges → 19 Special heating jackets, which can be ordered separately from Endress+Hauser as an accessory, are available for the sensors. Endress+Hauser... -
Page 24: Mechanical Construction
Proline Promass 80S, 83S Mechanical construction Design/dimensions Dimensions Field housing compact version, powder-coated die-cast aluminum → 25 Transmitter compact version, stainless steel → 27 Transmitter connection housing remote version (II2G, Zone 1) → 27 Transmitter remote version, wall-mount housing (non hazardous area and II3G, zone 2) →... -
Page 25: Field Housing Compact Version, Powder-Coated Die-Cast Aluminum
Proline Promass 80S, 83S Field housing compact version, powder-coated die-cast aluminum a0006881 Dimensions in SI units * (without local display) dependent on respective process connection All dimensions in [mm] Dimensions in US units ³⁄₈" 9.08 8.28 7.48 6.72 11.02 4.25 15.28... - Page 26 Proline Promass 80S, 83S Field housing compact version (II2G, Zone 1), powder-coated die-cast aluminum Nicht-eigensichere Nicht-eigensichere Stromkreise durch IP40-Abdeckung geschützt IP40-Abdeckung geschützt Non-intrinsically safe Non-intrinsically safe circuits Ip40 protected Boucles de courant Boucles de courant sans sécurité intrinsèque sans sécurité intrinsèque protégées par Ip40...
-
Page 27: Transmitter Compact Version, Stainless Steel
Proline Promass 80S, 83S Transmitter compact version, stainless steel a0002245 Dimensions in SI and US units [mm] [in] [mm] [in] [mm] [in] 8.86 6.02 6.61 Transmitter connection housing remote version (II2G, Zone 1) Nicht-eigensichere Stromkreise durch IP40-Abdeckung geschützt Non-intrinsically safe... -
Page 28: Transmitter Remote Version, Wall-Mount Housing (Non Hazardous Area And Ii3G, Zone 2)
Proline Promass 80S, 83S Transmitter remote version, wall-mount housing (non hazardous area and II3G, zone 2) a0001150 Dimensions (SI units) 90.5 159.5 > 50 81.5 11.5 8 × M5 2 × ⌀ 6.5 Securing screw for wall mounting: M6 (screw head max. 10.5 mm) -
Page 29: Transmitter Remote Version, Connection Housing
Proline Promass 80S, 83S Transmitter remote version, connection housing a0002516 Dimensions in SI units 118.5 137.5 118.5 137.5 118.5 137.5 118.5 137.5 118.5 137.5 All dimensions in [mm] Dimensions in US units ³⁄₈" 4.67 5.41 5.43 ½" 4.67 5.41 5.43 1"... -
Page 30: Process Connections In Si Units
Proline Promass 80S, 83S Process connections in SI units Flange according to EN 1092-1 (DIN 2501), PN 40 Flange according to EN 1092-1 (DIN 2501), PN 63 +1.5 (+0.06) –2.0 (–0.08) A0022147 Engineering unit mm (in) Flange according to EN 1092-1 (DIN 2501), PN 40: 1.4404 (F316/F316L) Surface roughness (flange): EN 1092-1 Form B1 (DIN 2526 Form C), Ra 3.2 to 12.5 μm... -
Page 31: Flange According To Asme B16.5, Cl 150
Proline Promass 80S, 83S Flange according to ASME B16.5, Cl 150 Flange according to ASME B16.5, Cl 300 +1.5 (+0.06) –2.0 (–0.08) A0022147 Engineering unit mm (in) Flange according to ASME B16.5, Cl 150: 1.4404 (F316/F316L) Surface roughness (flange): Ra 126 to 248 μm Order code for "Process connection", option AAZ... -
Page 32: Jis B2220 Flange, 10K
Proline Promass 80S, 83S JIS B2220 flange, 10K JIS B2220 flange, 20K JIS B2220 flange, 40K +1.5 (+0.06) –2.0 (–0.08) A0022147 Engineering unit mm (in) JIS B2220 flange, 10K: 1.4404 (F316/F316L) Surface roughness (flange): Ra 3.2 to 6.3 μm Order code for "Process connection", option NEZ 1071 4 ×... -
Page 33: Tri-Clamp, Din 11866 Line C
Proline Promass 80S, 83S Tri-Clamp, DIN 11866 line C Tri-Clamp 1", DIN 11866 line C Tri-Clamp ¾", DIN 11866 line C Tri-Clamp ½", DIN 11866 line C All Tri-Clamp connections correspond to the relevant ASME BPE hygienic clamp dimensions. DN 25, 40, 50 (1", 1½", 2") -
Page 34: Din 11851 Thread, Din 11866 Line Adin 11851 Thread Rd 28 × ¹⁄₈", Din 11866 Line A
Proline Promass 80S, 83S Tri-Clamp ½", DIN 11866 line C: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FUG Clamp ½" 25.0 9.40 12.00 All dimensions in [mm] DIN 11851 thread, DIN 11866 line A DIN 11851 thread Rd 28 ×... -
Page 35: Din 11864-1A Thread, Din 11866 Line A
Proline Promass 80S, 83S DIN 11864-1A thread, DIN 11866 line A +1.5 (+0.06) –2.0 (–0.08) A0022150 Engineering unit mm (in) DN 11864-1A thread, DIN 11866 line A: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FLH Rd 34 ×... -
Page 36: Din 11864-2A Flange, Din 11866 Line A, Flange With Notch
Proline Promass 80S, 83S DIN 11864-2A flange, DIN 11866 line A, flange with notch +1.5 (+0.06) –2.0 (–0.08) A0022151 Detail A: The flange has the smaller groove for the O-ring on the sensor side. When mounting the sensor the corresponding flange must have accordingly a larger groove. -
Page 37: Din 11864-3A Clamp, Din 11866 Line A, With Notch
Proline Promass 80S, 83S DIN 11864-3A clamp, DIN 11866 line A, with notch +1.5 (+0.06) –2.0 (–0.08) A0022152 Engineering unit mm (in) DIN 11864-3A clamp, DIN 11866 line A, with notch: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FWA... -
Page 38: Din 32676 Clamp, Din 11866 Line A
Proline Promass 80S, 83S DIN 32676 clamp, DIN 11866 line A +1.5 (+0.06) –2.0 (–0.08) A0022182 Engineering unit mm (in) DIN 32676 clamp, DIN 11866 line A: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FDW 34.0... -
Page 39: Iso 2852 Clamp, Iso 2037
Proline Promass 80S, 83S ISO 2852 clamp, ISO 2037 +1.5 (+0.06) –2.0 (–0.08) A0022182 Engineering unit mm (in) ISO 2852 clamp, ISO 2037: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FEA 50.5 22.60... -
Page 40: Iso 2853 Thread, Iso 2037
Proline Promass 80S, 83S ISO 2853 thread, ISO 2037 +1.5 (+0.06) –2.0 (–0.08) A0022153 Engineering unit mm (in) ISO 2853 thread, ISO 2037: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FJG 37.13 22.60... -
Page 41: Sms 1145 Thread
Proline Promass 80S, 83S SMS 1145 thread +1.5 (+0.06) –2.0 (–0.08) A0022154 Engineering unit mm (in) SMS 1145 thread: 1.4435 (316L) Surface roughness: Ra ≤ 0.8 μm/150 grit Order code for "Process connection", option FSD Rd 40 × 1/6" 22.50 8.31... -
Page 42: Flange According To Asme B16.5, Cl 150 Flange According To Asme B16.5, Cl 300
Proline Promass 80S, 83S Process connections in US units Flange according to ASME B16.5, Cl 150 Flange according to ASME B16.5, Cl 300 +1.5 (+0.06) –2.0 (–0.08) A0022147 Engineering unit mm (in) Flange according to ASME B16.5, Cl 150: 1.4404 (F316/F316L) Surface roughness (flange): Ra 126 to 248 μin... -
Page 43: Tri-Clamp, Din 11866 Line C Tri-Clamp 1", Din 11866 Line C Tri-Clamp ¾", Din 11866 Line C
Proline Promass 80S, 83S Tri-Clamp, DIN 11866 line C Tri-Clamp 1", DIN 11866 line C Tri-Clamp ¾", DIN 11866 line C Tri-Clamp ½", DIN 11866 line C DN 25, 40, 50 (1", 1½", 2") +1.5 (+0.06) –2.0 (–0.08) DN 8, 15 (½", ¾") - Page 44 Proline Promass 80S, 83S Tri-Clamp ½", DIN 11866 line C: 1.4435 (316L) Surface roughness: Ra ≤ 32 μin/150 grit Order code for "Process connection", option FUG Clamp ½" ½" 0.98 18.35 0.37 0.47 All dimensions in [in] SMS 1145 thread +1.5...
-
Page 45: Weight
Proline Promass 80S, 83S Purge connections, secondary containment monitoring a0003288 [mm] [in] [mm] [in] [mm] [in] [mm] [in] ³⁄₈" ½"-NPT 0.98 3.23 4.34 ½" ½"-NPT 0.98 3.23 8.04 1" ½"-NPT 0.98 3.23 13.54 1½" ½"-NPT 1.77 4.02 20.70 2" ½"-NPT 2.28... -
Page 46: Materials
Proline Promass 80S, 83S Materials Transmitter housing Compact version • Powder coated die-cast aluminium • Stainless steel housing: stainless steel, 1.4301 (304) • Window material: glass or polycarbonate Remote version • Remote field housing: powder-coated die-cast aluminium • Wall-mount housing: powder coated die-cast aluminium •... -
Page 47: Operability
Proline Promass 80S, 83S Operability Local operation Display elements • Liquid-crystal display: backlit, two lines (Promass 80) or four lines (Promass 83) with 16 characters per line • Selectable display of different measured values and status variables • At ambient temperatures below –20 °C (–4 °F) the readability of the display may be impaired. -
Page 48: Certificates And Approvals
• EHEDG tested TSE compliance Endress+Hauser declare, that no material with animal origin or ingredients of animal origin are being used during the entire production of Promass sensors produced in our Reinach / Switzerland, Cernay / France, Greenwood / USA or Aurangabad/India production facilities. -
Page 49: Pressure Measuring Device Approval
PED is required, this must be ordered explicitly. For devices with nominal diameters less than or equal to DN 25 (1"), this is neither possible nor necessary. • With the identification PED/G1/III on the sensor nameplate, Endress+Hauser confirms conformity with the "Basic safety requirements" of Appendix I of the Pressure Equipment Directive 97/23/EC. -
Page 50: Accessories
Proline Promass 80S, 83S Accessories Various accessories, which can be ordered with the device or subsequently from Endress+Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. -
Page 51: Service-Specific Accessories
Endress+Hauser representative for more information. FieldCare FieldCare is Endress+Hauser’s FDT-based plant asset management tool and allows the configuration and diagnosis of intelligent field devices. By using status information, you also have a simple but effective tool for monitoring devices. The Proline flowmeters are accessed via a service interface or via the service interface FXA193. -
Page 52: Documentation
Registered trademark of the Fieldbus FOUNDATION, Austin, USA Modbus ® Registered trademark of the Modbus Organization ® ® ® ® ® HistoROM™, S-DAT , T-DAT™, F-CHIP , Fieldcheck , FieldCare , Applicator Registered or registration-pending trademarks of Endress+Hauser Flowtec AG, Reinach, CH Endress+Hauser... -
Page 53: Endress+Hauser
Proline Promass 80S, 83S Endress+Hauser... - Page 54 www.addresses.endress.com...
