Dataproducts Parallel Interface - Printronix P7000 User Manual

Chapter 5

Dataproducts Parallel Interface

Dataproducts Parallel Interface
Table 8. Dataproducts Parallel Interface Connector Pin Assignments
(with a 50-pin AMP HDH-20 Data Cable Connector)
Input Signals
Signal Pin
DATA LINE 1 19
Return 3
DATA LINE 2 20
Return 4
DATA LINE 3 1
Return 2
DATA LINE 4 41
Return 40
DATA LINE 5 34
Return 18
DATA LINE 6 43
Return 42
DATA LINE 7 36
Return 35
DATA LINE 8 28
Return 44
DATA STROBE 38
Return 37
PAPER INSTRUCTION 30
Return 14
BUFFER CLEAR 31
Return 15
NOTE: Pins not listed are not connected.
The length of the data cable from the host computer to the printer must
not exceed 40 feet (12 meters).
294
Output Signals
Signal Pin
READY 22
Return 6
ONLINE 21
Return 5
DEMAND/DATA REQ. 23
Return 7
PARITY ERROR 27
11
Miscellaneous
Signal Pin
CABLE VERIFY 45, 46
GROUND 39
