Kenwood DPX-U5130 Service Manual page 4

Models for destination "M&H" (DPX-U5130, DPX-U5130BT, DPX5130BTPT4, DPXU5130MM3)
FM tuner section
Frequency range
Usable sensitivity (S/N= 26 dB)
Quieting sensitivity (DIN S/N = 46 dB)
Frequency response (± 3 dB)
Signal-to-Noise ratio (MONO)
Stereo separation (1 kHz)
AM tuner section
Frequency range
Usable sensitivity (S/N= 20 dB)
CD player section
Laser diode
Digital filter (D/A)
D/A converter
Spindle speed
Wow & Flutter
Frequency response (± 1 dB)
Total harmonic distortion (1 kHz)
Signal-to-Noise ratio (1 kHz)
Dynamic range
MP3 decode
WMA decode
AAC decode
USB interface
USB standard
File system
Maximum supply current
MP3 decode
WMA decode
AAC decode
WAV decode
Audio section
Maximum output power
Full bandwidth power
Speaker impedance
Tone action
Preout level / load (CD)
Preout impedance
Bluetooth section (DPX-U5130BT, DPX5130BTPT4 only)
Version
Frequency Range
Output Power
Maximum Communication range
Profile
Auxiliary input
Frequency response (± 3 dB)
Input maximum voltage
Input impedance
General
Operating voltage
Maximum current consumption
Installation size (W × H × D)
Weight
Subject to change without notice.
SPECIFICATION
87.9 MHz - 107.9 MHz (200 kHz space)
87.5 MHz - 108.0 MHz (50 kHz space)
7.2 dBf (0.63 µV/75 Ω)
15.2 dBf (1.6 µV/75 Ω)
30 Hz - 15 kHz
75 dB
45 dB
Band 1 (MW) 530 kHz to 1700 kHz (10 kHz space)
531 kHz to 1611 kHz (9 kHz space)
Band 2 (SW1) 2940 kHz to 7735 kHz (5 kHz space)
Band 3 (SW2) 9 500 kHz - 10135 kHz / 11580 kHz to 18135 kHz (5 kHz space)
MW: 31 dBµ (36 µV) / SW: 32 dBµ (40 µV)
GaAIAs
8 Times Over Sampling
24 Bit
500 rpm to 200 rpm (CLV)
Below Measurable Limit
20 Hz - 20 kHz
0.01%
105 dB
90 dB
Compliant with MPEG-1/2 Audio Layer-3
Compliant with Windows Media Audio
AAC-LC ".m4a" files
USB1.1/ 2.0 (Full speed)
FAT12/16/ 32
DC 5 V 1 A
Compliant with MPEG-1/2 Audio Layer-3
Compliant with Windows Media Audio
AAC-LC ".m4a" files
Linear-PCM
50 W × 4
22 W × 4 (at less than 1 % THD)
4 - 8 Ω
Bass 100 Hz ± 8 dB
Middle 1 kHz ± 8 dB
Treble 12.5 kHz ± 8 dB
2500 mV/10 kΩ
≤ 600 Ω
Bluetooth Ver. 2.1+EDR Certified
2.402 - 2.480 GHz
+4 dBm (MAX), 0 dBm (AVE) Power Class 2
Line of sight approx. 10m (32.8 ft)
HFP (Hands-Free Profile), SPP (Serial Port Profile), PBAP (Phonebook Access
Profile), OPP (Object Push Profile), A2DP (Advanced Audio Distribution Profile),
AVRCP (Audio/Video Remote Control Profile)
20 Hz - 20 kHz
1200 mV
10 kΩ
DPX-U5130BT: 14.4 V (10.5 - 16V allowable)
DPX-U5130: 14.4 V (11 - 16V allowable)
10 A
182 mm × 111 mm × 157 mm
1.5 kg
(No.WA063<Rev.003>)4/31
