Kenwood DPX-U5130 Service Manual page 28

4.11.5 Common operation mode
Operation
Signal Strength
Tuner Status
ENSA Lock Status
ENSB Lock Status
BER S1
BER S2
BER T
C/N S1A
VOL
C/N S1B
Up/Down
C/N S2A
C/N S2B
RSErrs Word
RSErrs Sat Symb
RSErrs Terr Symb
Tuner Carrier
Frequency Offset
Received Signal
Strength Indication
Display content
S I G
T N R
L C K A
L C K B
B E S 1
B E S 2
B E T
C N 1 A # #
C N 1 B # #
C N 2 A # #
C N 2 B # #
R S W
R S S
R S T
T F * # #
R S I *
(No.WA063<Rev.003>)28/31
Signal: 0x00 ~ 0x04(hex)
X # #
00 ~ 04 are displayed in "##".
Tuner STS:(hex) "##"
Bit0: PLL Lock, Bit1: Ant Det
Bit2: Ant Undr, Bit3: Ant Ovr
Bit4: RF AGC Eng,
X # #
Bit5: IF AGC Eng
Bit6,Bit7: Reserved
ENSA Lock Status:(hex) "##"
Bit0: T[mcm], Bit1: T[tdm]
Bit2: S2[qpsk], Bit3: S2[tdm]
X # #
Bit4: S1[qpsk], Bit5: S1[tdm]
Bit6,Bit7: Reserved
ENSB Lock Status:(hex) "##"
Bit0: T[mcm], Bit1: T[tdm]
Bit2: S2[qpsk], Bit3: S2[tdm]
X # #
Bit4: S1[qpsk], Bit5: S1[tdm]
Bit6,Bit7: Reserved
BER S1 : 0 ~ 100 (DEC) "###"
# # #
BER S2 : 0 ~ 100 (DEC) "###"
# # #
BER T : 0 ~ 100 (DEC) "###"
# # #
Satellite 1 Ensemble A carrier to noise ratio in dB.
The value is reported in 0.25 dB steps.
CN1A: 0.00 ~ 63.75(dB) (DEC) "##.##"
. # #
Eg. 0x3F→63/4 = 15.75 (dB)
Satellite 1 Ensemble B carrier to noise ratio in dB.
The value is reported in 0.25 dB steps.
. # # CN1B: 0.00 ~ 63.75(dB) (DEC) "##.##"
Eg. 0x3F→63/4 = 15.75 (dB)
Satellite 2 Ensemble A carrier to noise ratio in dB.
The value is reported in 0.25 dB steps.
. # # CN2A: 0.00 ~ 63.75(dB) (DEC) "##.##"
Eg. 0x3F→63/4 = 15.75 (dB)
Satellite 2 Ensemble B carrier to noise ratio in dB.
The value is reported in 0.25 dB steps.
. # # CN2B: 0.00 ~ 63.75(dB) (DEC) "##.##"
Eg. 0x3F→63/4 = 15.75 (dB)
The averaged rate of uncorrectable words.
# # # RS W : 0 ~ 100 (%) (DEC) "###"
The averaged symbol error rate of the RS decoder
of the satellite channels.
# # #
RS S : 0 ~ 100 (%) (DEC) "###"
The averaged symbol error rate of the RS decoder
of the terrestrial channels.
# # #
RS T : 0 ~ 100 (%) (DEC) "###"
INT16 value multiplied by 100. Values above 1000
(100000) may be represented as +99999
or -99999.
# # #
* : + / - , "#####"
Eg. 0 x FF86 → -123 x 100 = -12300
RSSI : 0 ~ -128 (dBm) (DEC)
value with INT16 value multiplied by 1.
* : + / - , "###"
# # #
Eg. 0xFF86→-123
0x007B→+123
Details
