HPI Racing MINI-TROPHY Instruction Manual page 44

7
Parts List Pièces détachées
パーツリスト
Ersatzteilliste
Parts List
En
Parts # Description
341 SC-15 Electronic Speed Control With Reverse
1146 Firebolt 15T Motor (540 Type)
6122 Body Pin (Medium/10pcs)
6163 Servo Tape 20x100mm (5pcs)
6816 Silicone O-Ring S10 (6pcs)
6819 Silicone O-Ring P-3 (Red/5pcs)
6918 Pinion Gear 18 Tooth (48 Pitch)
85053 Shock Body Set (12x70-103mm/2pcs)
85054 Shock Body Set (12x67-87mm/2pcs)
Gear Diff Bevel Gears (13T/10T/4pcs) ( ax2, bx2, cx1, dx2 )
86014
86094 Screw Shaft M4x2.5x12mm (Black/6pcs)
86227 Diff Shaft 5x22.5x7mm (2pcs)
86228 Axle 5x36x7mm (2pcs)
86233 Dogbone 7x57mm
Bevel Gear Set 38/13T (Sintered Metal) ( ax1, bx1 )
86324
86810 Gear Shaft 5x6x29mm
86880 Slipper Pressure Plate (2pcs)
86882 Suspension Shaft 3x32mm (2pcs)
86887 Suspension Shaft 3x54mm (2pcs)
86896 Ball Stud 4.8x12mm (10pcs)
86900 Slipper Pad (2pcs)
86916 Shock Spring 13x57x1.1mm 14.5coils (2.4lb,Blue)
86946 Spur Gear 87T (48 Pitch)
88133 Shock Shaft 3x42mm (2pcs)
88134 Shock Shaft 3x50mm (2pcs)
100318 Shock Parts Set
Helmet Parts Set ( ax1 )
102832
103037 ST-8 Wheel Matte Chrome (0mm Offset/4pcs)
103045 Gear Box Set
Front Suspension Arm Set ( ax2 )
103047
103051 Shock Cap Set (Front/Rear)
Main Chassis ( ax2 )
103057
Steering Arm / Servo Saver Set ( ax1 )
103059
103199 Front Skid Plate/Bumper Set
103201 Rear Skid Plate/Bumper Set
103203 Front Roll Cage Set
Motor Mount Set ( ax1, bx1, cx1 )
103211
103218 Bulkhead Set
103229 Roll Cage Brace Set
Front Brace Set ( ax1, bx1 )
103232
103765 Yokohama Geolander M/T Tire D Comp (94x34mm/2pcs)
Ersatzteileliste
De
Nummer Beschreibung
341 SC-15 Elektronischer Fahrtenregler (Rueckwaerts)
1146 Firebolt 15t Motor (540er)
6122 Karosseriesplinte Mittel (10 St.)
6163 Doppelseitiges Klebeband 20x100mm (5st)
6816 Silikon O-Ring S10 (6 St.)
6819 Silikon O-Ring P-3 (Rot/5st)
6918 Ritzel 18 Zaehne (48dp)
85053 Daempfergehaeuse Set (12x70-103mm/2st/Firestorm)
85054 Daempfergehaeuse Set (12x67-87mm/2st/Firestorm)
Kegeldiff Zahnraeder Inkl. Stift (4st) ( ax2, bx2, cx1, dx2 )
86014
86094 Gewindestift M4x2.5x12mm (Schwarz/6st)
86227 Diffwelle 5x22.5x7mm (2st)
86228 Achse 5x36x7mm (2st.)
86233 Knochen 7x57mm
Kegelrad Set (Gesintertes Metall/Mt2) ( ax1, bx1 )
86324
86810 Getriebewelle 5x6x29mm (Wheely King)
86880 Slipperscheiben (2st/Firestorm)
86882 Schwingenstift 3x32mm (2st/Firestorm)
86887 Schwingenstift 3x54mm (2st/Firestorm)
86896 Kugelkopf 4.8x12mm (10st/Firestorm)
86900 Slipperbelag (2st/Firestorm)
86916 Daempferfeder 13x57x1.1mm 14.5wdg (2.4lb/Blau)
86946 Hauptzahnrad 87z (48dp)
88133 Kolbenstange 3x42mm (2st/Brama 10b)
88134 Kolbenstange 3x50mm (2st/Brama 10b)
100318 Daempferteile Set (Firestorm)
Helm-Teile Set (Formula Ten) ( ax1 )
102832
103037 ST-8 Felge Matt-Chrom (0mm Offset/4st)
103045 Getriebebox Set
Schwingen Set Vorne ( ax2 )
103047
103051 Daempfergehaeuse Set (Vorne/Hinten)
Chassis ( ax2 )
103057
Lenkhebel / Servo Saver Set ( ax1 )
103059
103199 Skid Plate / Rammer Set Vorne
103201 Skid Plate / Rammer Set Hinten
103203 Ueberrollkaefig Set Vorne
Motorhalter Set ( ax1, bx1, cx1 )
103211
103218 Bulkhead Set
103229 Ueberrollkaefig-Streben Set
Streben Set Vorne ( ax1, bx1 )
103232
103765 Geolander M/T Reifen D Mischung (94x34mm/2st)
Parts # Description
103773 Plastic Truck Bed Tires (2pcs)
Center Drive Shaft Set ( ax1, bx1, cx1, dx1 )
104144
104215 DT-1 Truck Body (Painted Color)
104717 DT-1 Truck Body (Painted Color)
104719 Rear Suspension Arm Set
Universal Joint Set ( ax2, bx1, cx1 )
104721
104815 Inner Body Set For Dt-1 Truck Body
Upright Set (Left/Right) ( ax1, bx1, cx2, dx2 )
104851
105041 Shock Spring 13x70x1.4mm 9.5coils (Black)
Diff Case ( ax1, bx1 )
A431
B022 Ball Bearing 5x11x4mm (2pcs)
B030 Ball Bearing 10x15x4mm (2pcs)
Antenna Pipe Set ( ax1, bx1 )
Z150
Z242 E Clip E2mm (20pcs)
Z243 E Clip E3mm (10pcs)
Z264 Pin 2x10mm Silver (10pcs)
Z299 Step Screw M3x23mm (4pcs)
Z481 TP. Binder Head Screw M2.6x8mm (12pcs)
Z517 Binder Head Screw M3x8mm (10 Pcs)
Z518 Binder Head Screw M3x12mm (6pcs)
Z519 Binder Head Screw M3x15mm (6pcs)
Z526 Flat Head Screw M3x8mm (6pcs)
Z527 Flat Head Screw M3x10mm (6pcs)
Z561 Tp. Flanged Screw M3x10mm (6pcs)
Z567 Tp. Binder Head Screw M3x10mm (10pcs)
Z569 Tp. Binder Head Screw M3x15mm (10pcs)
Z571 Tp. Binder Head Screw M3x20mm (6pcs)
Z573 Tp. Binder Head Screw M3x25mm (6pcs)
Z578 Tp. Flat Head Screw M3x12mm (10pcs)
Z579 Tp. Flat Head Screw M3x15mm (12pcs)
Z581 Tp. Flat Head Screw M3x18mm (10pcs)
Z663 Lock Nut M3 (6pcs)
Z684 Flanged Lock Nut M4 (4pcs)
Z700 Set Screw M3x3mm (6pcs)
Z705 Set Screw M3x10mm (6pcs)
Z713 Set Screw M3x30 (10pcs)
Z852 Washer 5x7x0.2mm (10pcs)
Z892 Washer 10x12x0.2mm (10pcs)
Z901 Allen Wrench 1.5mm
Z904 Allen Wrench 2.0mm
Z950 Cross Wrench (Small)
Nummer Beschreibung
103773 Plastik Reifen-Dummy (Fuer Vitrine/2st)
Mittelantriebs-Welle Set ( ax1, bx1, cx1, dx1 )
104144
104215 DT-1 Truck Karosserie (Lackiert)
104717 O-Ring 4x7x1.5mm (8st)
104719 Schwingen Set Hinten
Kardan Set ( ax2, bx1, cx1 )
104721
104815 Innenkarosserie Set Fuer DT-1 Truck Karosserie
Lenkhebeltraeger Set (Links/Rechts) ( ax1, bx1, cx2, dx2 )
104851
105041 Daempferfeder 13x70x1.4mm 9.5WDG (Schwartz)
Differentialgehaeusesatz ( ax1, bx1 )
A431
B022 Kugellager 5x11x4mm (2st)
B030 Kugellager 10x15x4mm (2st)
Antennenrohrset ( ax1, bx1 )
Z150
Z242 E-Clip E2mm Silber (20st)
Z243 E-Clip E3mm (10st)
Z264 Stift 2x10mm Silber (10st)
Z299 Stufenschraube 3x23mm (4st)
Z481 Flachkopfschneidschraube M2.6x8mm (12st)
Z517 Flachkopfschraube M3x8mm Schwarz (10st)
Z518 Flachkopfschraube M3x12mm Schwarz (6st)
Z519 Flachkopfschraube M3x15mm Schwarz (6st)
Z526 Senkkopfschraube M3x8mm(6st)
Z527 Senkkopfschraube M3x10mm(6st)
Z561 Schneidschraube Mit Flansch M3x10mm (6st)
Z567 Flachkopfschneidschraube M3x10mm (10st)
Z569 Flachkopfschneidschraube M3x15mm (10st)
Z571 Flachkopfschneidschraube M3x20mm (6st)
Z573 Flachkopfschneidschraube M3x25mm (6st)
Z578 Senkkopfschneidschraube M3x12mm (10st)
Z579 Senkkopfschneidschraube M3x15mm (12st)
Z581 Senkkopfschneidschraube M3x18mm (10st)
Z663 Stoppmutter M3 (6st)
Z684 Stoppmutter M4 Mit Flansch (4st)
Z700 Madenschraube M3x3mm (6st)
Z705 Madenschraube M3x10mm (6st)
Z713 Madenschraube M3x30mm (10st)
Z852 Unterlagscheibe 5x7x0.2mm (10st)
Z892 Unterlagscheibe 10x12x0.2mm (10st)
Z901 Inbusschluessel 1.5mm
Z904 Inbusschluessel 2.0mm
Z950 Kreuzschluessel Klein
44
