Use the following procedure to configure OSPFv3 support as shown in
1. Configure IPv6 interfaces for each link which will be attached to OSPFv3 areas.
RS G8000(config)# interface ip 3
RS G8000(config-ip-if)# ipv6 address 10:0:0:0:0:0:0:1
RS G8000(config-ip-if)# ipv6 prefixlen 56
RS G8000(config-ip-if)# enable
RS G8000(config-ip-if)# exit
RS G8000(config)# interface ip 4
RS G8000(config-ip-if)# ip address 36:0:0:0:0:0:1
RS G8000(config-ip-if)# ipv6 prefixlen 56
RS G8000(config-ip-if)# enable
RS G8000(config-ip-if)# exit
This is equivalent to configuring the IP address and netmask for IPv4 interfaces.
2. Enable OSPFv3.
RS G8000(config)# ipv6 router ospf
RS G8000(config-router-ospf3)# enable
This is equivalent to the OSPFv2 enable option in the router ospf command
path.
3. Define the backbone.
RS G8000(config-router-ospf3)# area 0 area-id 0.0.0.0
RS G8000(config-router-ospf3)# area 0 type transit
RS G8000(config-router-ospf3)# area 0 enable
This is identical to OSPFv2 configuration.
4. Define the stub area.
RS G8000(config-router-ospf3)# area 1 area-id 0.0.0.1
RS G8000(config-router-ospf3)# area 1 type stub
RS G8000(config-router-ospf3)# area 1 enable
RS G8000(config-router-ospf3)# exit
This is identical to OSPFv2 configuration.
5. Attach the network interface to the backbone.
RS G8000(config)# interface ip 3
RS G8000(config-ip-if)# ipv6 ospf area 0
RS G8000(config-ip-if)# ipv6 ospf enable
RS G8000(config-ip-if)# exit
The ipv6 command path is used instead of the OSPFv2 ip command path
6. Attach the network interface to the stub area.
RS G8000(config)# interface ip 4
RS G8000(config-ip-if)# ipv6 ospf area 1
RS G8000(config-ip-if)# ipv6 ospf enable
RS G8000(config-ip-if)# exit
The ipv6 command path is used instead of the OSPFv2 ip command path
Figure 33:
