Note: This must be done before disarming the system.
4. When system testing is completed, disarm the system.
5. Call the central station to verify that the alarms were received.
Note: If optional system components are utilized, they should be validated as properly functioning and operational.
Enabling the System for Use
After installation, programming, configuration, and testing, do the following to complete the installation:
•
Adjust system parameters (chime, background, screen saver, etc.).
•
Configure and enable desired applications for end user use.
•
Change the panel name (Advisor1) to the desired panel name, such as Smith Household.
Changing the Panel Name
The panel comes factory installed with the panel name of AdvisorOne. The installer should change the panel name to personalize the
panel for the end user.
1. Press the Settings icon
2. Press CONFIGURATION to enter programming.
3. Enter the installer code or dealer code.
4. Press SYSTEM OPTIONS from the Configuration & Programming screen.
5. Press PANEL from the System Options screen.
On the Panel Options screen, across from Name, press "AdvisorOne" to bring up the keyboard, then enter the new panel name
6.
(for example, Smith Household, Smith Residence, Smith Security System).
Note: If no name is desired, change the panel name from AdvisorOne to "(space bar)". The panel will not speak the panel name.
Disposal
Dispose of all equipment in accordance with local requirements.

Specifications

Dimensions
Power
Backup Battery
Hardwired Terminals
Sensor Radio Frequency
WAN/LAN
Storage Temperature
Operating Temperature
Maximum Humidity
AdvisorOne Panel Quick Installation Guide
on the lower left of the main screen.
8.7" x 6.4" x 1.7" (220 mm x 162 mm x 43 mm)
120V 60Hz 550mA to 12 VDC, 2 amp power supply (P/N AV-PS12V)
Rechargeable battery: 7.2 VDC, 2800 mAh NIMH (P/N AVO-BAT28A)
IN4 and IN5: Vin maximum 12 V. Vin low 0 V.
Input impedance: 5 K
OUT1 and OUT2: 12 VDC maximum (not a power source, can sink up to 50 mA each).
Relay: 30 VDC/2.0 A (maximum)
Siren : unregulated 5 – 12 VDC/250 mA (maximum)
Aux power: unregulated 5 –12 VDC/150 mA (maximum)
Siren and aux power outputs: combined 400 mA (maximum)
319.5 MHz
10/100 Mbps
-29 to 140ºF (-34 to 60ºC) without battery
14 to 86ºF (-10 to 30ºC) with battery one year shelf life
32 to 122ºF (0 to 49ºC)
85% relative humidity, noncondensing
