System Tests - Interlogix AdvisorOne Panel Quick Installation Manual

Configuring a User
Only a dealer in advance configuration and the Master Code can create users. The Installer cannot add users.
1. From the Configuration & Programming screen, press USERS.
2. From the Users screen, press USERS.
3. From the list of current users, press ADD.
4. From the User configuration screen, configure the user options (see Table 7 for the necessary options).
5. Press SAVE to save the options.
Table 7: User Options
Option Description
User Name The name assigned to the user.
User PIN Number The access code assigned to the user.
User Language Press the icon next to User language to select the language.
Authority Press SELECT to assign authority levels to users.
Off-Premises Communication
The AdvisorOne system can be programmed to a central monitoring station in the following ways:
•
PSTN and/or
Accessing Central Monitoring Station Programming Options
1. From the Configuration & Programming screen, press COMMUNICATION.
2. From the Communication screen, press REPORTING.
3. Press EDIT to select the central station to program and follow the programming options.
Access to automatic communication test is located in the advanced programing tab (Communication, Reporting, Destination, Edit –
Main Options). The automatic phone test duration should be set to 7 days for all communication methods used.
Note: For proper supervision, ensure that the "line cut" option is set to on.
Network addressing of devices shall not make use of public domain name servers
Completing the Configuration and Programming
1. Exit the Configuration and Programming to return to the main screen.
2. Verify that there are no trouble conditions.
If there are no trouble conditions, move on to the System Tests section.
Note: If there are trouble conditions, trouble beeps will continually sound. Trouble beeps can be disabled or suppressed.
•
Disabling Trouble Beeps: To permanently disable trouble beeps, press the Settings icon
access code. After entering the access code, press CONFIGURATION/SYSTEM OPTIONS/PARTITIONS and press EDIT.
Select DISABLE across from Trouble Beeps then press SAVE.
•
Suppressing Trouble Beeps: To temporarily suppress trouble beeps, press the system status icon
Entering the system status screen will suppress trouble beeps for the factory default of 4 hours.

System Tests

Notify the central station when executing any test procedure. When testing is complete, notify the central station. Otherwise, authorities
could be dispatched to the site and fines levied.
Sensor Testing
Test the sensors and key fobs after all programming is completed and whenever a sensor-related problem occurs.
AdvisorOne Panel Quick Installation Guide
•
Ethernet
and enter the installer or dealer
from the main screen.
9 / 18
