3. For adding a new rule, click Add to open the following page.
Available settings are explained as follows:
Item
ACT
Ethernet Type
Local Address
Remote Address
Edit
DiffServ CodePoint
Service Type
Vigor2920 Series User's Guide
Description
Check this box to invoke these settings.
Please specify which protocol (IPv4 or IPv6) will be used for
this rule.
Click the Edit button to set the local IP address (on LAN) for
the rule.
Click the Edit button to set the remote IP address (on
LAN/WAN) for the rule.
It allows you to edit source address information.
Address Type – Determine the address type for the source
address.
For Single Address, you have to fill in Start IP address.
For Range Address, you have to fill in Start IP address and
End IP address.
For Subnet Address, you have to fill in Start IP address and
Subnet Mask.
All the packets of data will be divided with different levels and
will be processed according to the level type by the system.
Please assign one of the levels of the data for processing with
QoS control.
It determines the service type of the data for processing with
QoS control. It can also be edited. You can choose the
predefined service type from the Service Type drop down list.
