Available settings are explained as follows:
Item
PPPoE Client Mode
ISP Access Setup
WAN Connection
Detection
MTU
PPPoE Pass-through
PPP/MP Setup
IP Address Assignment
Method (IPCP)
Vigor2920 Series User's Guide
Description
Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
Enter your allocated username, password and authentication
parameters according to the information provided by your ISP.
Username – Type in the username provided by ISP in this
field.
Password – Type in the password provided by ISP in this
field.
Index (1-15) in Schedule Setup - You can type in four sets of
time schedule for your request. All the schedules can be set
previously in Application – Schedule web page and you can
use the number that you have set in that web page.
Such function allows you to verify whether network
connection is alive or not through ARP Detect or Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you
have to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL
value is set by telnet command.
It means Max Transmit Unit for packet. The default setting is
1442.
The router offers PPPoE dial-up connection. Besides, you also
can establish the PPPoE connection directly from local clients
to your ISP via the Vigor router. When PPPoA protocol is
selected, the PPPoE package transmitted by PC will be
transformed into PPPoA package and sent to WAN server.
Thus, the PC can access Internet through such direction.
For Wired LAN – If you check this box, PCs on the same
network can use another set of PPPoE session (different with
the Host PC) to access into Internet.
For Wireless LAN – If you check this box, PCs on the same
wireless network can use another set of PPPoE session
(different with the Host PC) to access into Internet.
PPP Authentication – Select PAP only or PAP or CHAP for
PPP. If you want to connect to Internet all the time, you can
check Always On.
Idle Timeout – Set the timeout for breaking down the Internet
after passing through the time without any action.
Usually ISP dynamically assigns IP address to you each time
you connect to it and request. In some case, your ISP provides
service to always assign you the same IP address whenever
you request. In this case, you can fill in this IP address in the
Fixed IP field. Please contact your ISP before you want to use
this function.
