Item
After finishing all the settings here, please click OK to activate them.
D e t a i l s
D e t a i l s
To use PPTP/L2TP as the accessing protocol of the internet, please choose PPTP/L2TP from
Internet Access menu. The following web page will be shown.
Available settings are explained as follows:
Item
PPTP/L2TP Client
Mode
Vigor2920 Series User's Guide
Description
IP Address: Type the IP address.
Subnet Mask: Type the subnet mask.
Gateway IP Address: Type the gateway IP address.
Default MAC Address: Click this radio button to use default
MAC address for the router.
Specify a MAC Address: Some Cable service providers
specify a specific MAC address for access authentication. In
such cases you need to click the Specify a MAC Address and
enter the MAC address in the MAC Address field.
DNS Server IP Address - Type in the primary IP address for
the router if you want to use Static IP mode. If necessary, type
in secondary IP address for necessity in the future.
P a g e f o r P P T P / L 2 T
P a g e f o r P P T P / L 2 T
Description
Enable PPTP- Click this radio button to enable a PPTP client
to establish a tunnel to a DSL modem on the WAN interface.
Enable L2TP - Click this radio button to enable a L2TP client
to establish a tunnel to a DSL modem on the WAN interface.
Disable – Click this radio button to close the connection
through PPTP or L2TP.
P i n W A N 1 / W A N 2
P i n W A N 1 / W A N 2
112
