1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item
Name
Interface
Address Type
Description
Type a name for this profile. Maximum 15 characters are
allowed.
Choose a proper interface.
For example, the Direction setting in Edit Filter Rule will ask
you specify IP or IP range for WAN or LAN or any IP address.
If you choose LAN as the Interface here, and choose LAN as
the direction setting in Edit Filter Rule, then all the IP
addresses specified with LAN interface will be opened for you
to choose in Edit Filter Rule page.
Determine the address type for the IP address.
Select Single Address if this object contains one IP address
only.
Select Range Address if this object contains several IPs within
a range.
Select Subnet Address if this object contains one subnet for IP
