Each item is explained as follows:
Item
Index
Display Name
Physical Mode
Access Mode
Details Page
IPv6
D e t a i l s P a g e f o r P
D e t a i l s P a g e f o r P
To choose PPPoE as the accessing protocol of the internet, please select PPPoE from the
Internet Access menu. The following web page will be shown.
Description
Display the WAN interface.
It shows the name of the WAN1/WAN2/WAN3 that entered
in general setup.
It shows the physical connection for WAN1(Ethernet)/WAN2
(Ethernet) /WAN3 (3G USB Modem) according to the real
network connection.
Use the drop down list to choose a proper access mode. The
details page of that mode will be popped up. If not, click
Details Page for accessing the page to configure the settings.
This button will open different web page according to the
access mode that you choose in WAN interface.
This button will open different web page (based on Physical
Mode) to setup IPv6 Internet Access Mode for WAN
interface.
If IPv6 service is active on this WAN interface, the color of
"IPv6" will become green.
P P o E i n W A N 1 / W A
P P o E i n W A N 1 / W A
107
N 2
N 2
