Cancel Navigation discards the current route and exits Navigation Mode. This menu option will only
appear when you are currently navigating a route. This will not delete a previously-saved route.
Active Side allows you to select a side of the screen in a Combo View. After you choose an active
side, you can apply menu settings and key commands to the view you've selected. The Active Side
menu option is only available when a Combo View is on the screen (see Views: Combo Views).
• A green arrow on the Combo View points to the active side.
• When a menu is displayed in the active side, the non-active side of the screen will be
grayed out.
Split Position sets the size of the left side of the Combo View. Each Combo View can be set
individually. The Split Position menu option is only available when a Combo View is on the screen
(see Views: Combo Views).
• The number setting indicates the percentage taken up by the left side of the Combo View.
• Selecting Left sets the left side of the screen to its smallest setting.
Cancel Navigation
(only when Navigating)
Settings: Press the RIGHT Cursor key and follow screen instructions.
Active Side
(Combo Views only)
Settings: Left, Right; Default = Left
Split Position
(Combo Views only)
Settings: Left, 30, 40, 50, 60, 70, Right; Default = Various
81
Sonar X-Press Menu
