Preview Window: As you scroll, the selected item's information is displayed on the right
E
side of the Waypoint Management dialog box. Press the +/– ZOOM keys to view the
position closer or farther away in the preview window.
Information: Displays the default group where all new waypoints, routes, and tracks will
F
be saved. In this illustration, Home is the default group. This field also changes to display
instructions.
Directory: Shows the directory structure and the currently selected group. The illustration
G
shows group GP070 as the selected group.
Arrows: When arrows are displayed on a menu option, additional information or
H
submenus are available. If the arrow points to the right, press the RIGHT Cursor key. If
the arrow points to the left, press the LEFT Cursor key to move up to the higher level
group directory.
Waypoint Icon: The blue circle icon is the default waypoint icon. Waypoint names are
I
alphanumeric and begin with WP. You can also change the icon, waypoint name, add it
to a route, and more. If the waypoint is saved with a snapshot or recording file, see the
Snapshot and Recording View on your control head to view the snapshot or recording.
Track Icon: Track names are saved with a date and time stamp, and certain track
J
information can be edited (see Edit your Waypoints, Routes, Tracks, and Groups).
Route Icon: Route names are alphanumeric and begin with R. To change the Route name
K
and its waypoints, see Edit your Waypoints, Routes, Tracks, and Groups.
61
Introduction to Navigation
