Frame Relay Configuration - Netopia R5100 User Reference Manual

8-8 User's Reference Guide
If you chose Frame Relay as your data link encapsulation type you can now configure the Frame Relay options
from the WAN Configuration menu.
Return/Enter for WAN line configuration.
From here you will configure yours and the remote sites' WAN information.
From the WAN Configuration screen, select WAN Setup, then select the Frame Relay Configuration option and
press Return. The Frame Relay Configuration screen appears.
LMI Type...
T391 (Polling Interval in secs):
N391 (Polls/Full Status Cycles):
N392 (Error Threshold):
N393 (Monitored Event Window):
Tx Injection Management...
Default CIR:
Default Bc:
Default Be:
Congestion Management Enabled:
Maximum Tx Frame Size:
Return/Enter goes to new screen.
Enter Information supplied to you by your telephone company.
1. Select LMI Type (Link Management Type) and press Return. From the pop-up menu, highlight either ANSI
(Annex D), CCITT (Annex A), LMI, or None. The default is None. Press Return.
WAN Configuration
WAN (Wide Area Network) Setup...
Display/Change Connection Profile...
Add Connection Profile...
Delete Connection Profile...
Default Profile...
Frame Relay Configuration...
Frame Relay DLCI Configuration...
Frame Relay Configuration
ANSI (Annex D)
10
6
3
4
Standard
64000
64000
0
No
1520
