Netopia R5100 User Reference Manual page 152

12-4 User's Reference Guide
-PWR-+-----WAN1------+--CON--AUX--+-----WAN2------+--EN--+--------LEDS---------
LNK RDY CH1 Ch2 LNK LNK LNK RDY CH1 CH2 DATA | '-'= Off 'G'= Green
G - G - - Y - - - - - - | 'R'= Red 'Y'= Yellow
Each LED representation can report one of four states:
–: The LED is off.
R: The LED is red.
G: The LED is green.
Y: The LED is yellow.
The section Netopia R5000 Series Router status lights on page 3-5 describes the meanings of the colors for
each LED.
Main
Statistics & Logs General Statistics
Menu
When you are troubleshooting your Netopia R5000 Series Router, the Statistics & Logs screens provide insight
into the recent event activities of the router.
From the Main Menu go to Statistics & Logs and select one of the options described in the sections that follow.
