2.4 Dimension Data

71
Model
RY24PEV1K
RY30PEV1K
R30PEV1K
RY36PEY1K
RY36PEY1K
RY42PEY1K
R42PEY1K
RY48PEY1K
RY48PEY1K
Figure 2-4-1
A
B
1018
412
980
427
1018
412
1107
440
C
D
695
572
790
610
840
572
1100
631
INSTALLATION
SiK401004_A
Unit : mm
E
378
395
378
400
