3.4.7 Air Exchange Setting *

Turn on air function: Under on-state of the unit, press Function button into this function
There are 10 types of AIR, but only 1-2 types are for remote control. Refer to the following
details:
1――The unit continuously runs for 60min, and fresh air valve runs for 6 min.
2――The unit continuously runs for 60min, and fresh air valve runs for 12 min.
3――The unit continuously runs for 60min, and fresh air valve runs for 18 min.
4――The unit continuously runs for 60min, and fresh air valve runs for 2 4 min.
5――The unit continuously runs for 60min, and fresh air valve runs for 30 min.
6――The unit continuously runs for 60min, and fresh air valve runs for 36 min.
7――The unit continuously runs for 60min, and fresh air valve runs for 42 min.
8――The unit continuously runs for 60min, and fresh air valve runs for 48 min.
9――The unit continuously runs for 60min, and fresh air valve runs for 54 min.
10――The unit continuously runs for 60min, and fresh air valve always runs.
Turn off air function: During Air function, press Function button into Air function. In this
case, air mark is blinking, and then press Enter/Cancel button to turn off this function. Air
mark will subsequently disappear.
Air setting is shown as in fig.3.4.7:
Note: In air exchange mode, press Function button or there is not any operation within 5s
47
setting (Air mark blinks). AIR 1 displayed at the ambient
temperature-displayed location (888) is defaulted (the last type of
AIR will be displayed after adjustment). Press ▲ or ▼ button to
adjust air type. Press Enter/Cancel button to turn on/off air function.
After turning on this function, the air mark shows.
after the lastbutton operation, the system will be quit from air exchange setting and
current energy-saving data won't be memorized.
Fig.3.4.7 Air exchange device
SiK401004_A
