Summary of Contents for Fisher & Paykel OB30 Series

  • Page 1 User guide Aerotech oven OB30 models US CA...
  • Page 3 This user guide is an accompaniment to your ‘Quick start guide’ which is included with your oven. For operating instructions, and to get going with your new oven see your ‘Quick start guide’ . If you no longer have your ‘Quick start guide’ , you can download it from our local website, listed on the back cover.
  • Page 5: Table Of Contents

    Contents Safety and warnings Cooking guide Oven functions Cooking charts Automatic cooking Using the meat probe User preference settings Sabbath setting Care and cleaning Using the Self Clean function Troubleshooting Alert codes Warranty and service Important! SAVE THESE INSTRUCTIONS The models shown in this user guide may not be available in all markets and are subject to change at any time.
  • Page 6: Safety And Warnings

    Safety and warnings Your oven has been carefully designed to operate safely during normal cooking procedures. Please keep the following safety instructions in mind when you are using it: WARNING! Electrical Shock Hazard Turn the oven off at the wall before replacing the oven lamp. Failure to follow this advice may result in death or electrical shock.
  • Page 7: Important Safety Instructions

    Safety and warnings WARNING! Cut Hazard Take care - some edges are sharp. Failure to use caution could result in injury or cuts. Important safety instructions To reduce the risk of fire, electrical shock, injury to persons or damage when using the oven, follow the important safety instructions listed below: Read all the instructions before using the oven.
  • Page 8 Safety and warnings Important safety instructions Use only dry oven mitts or potholders. Moist or damp potholders on hot surfaces could result in burns from steam. Do not let potholders touch hot areas or heating elements. Do not use a towel or a bulky cloth for a potholder.
  • Page 9 Safety and warnings Important safety instructions Before starting a Self Clean cycle, remove oven shelves, side racks, and all other cookware/ utensils, and wipe up large food spills or grease deposits. Before starting a Self Clean cycle, make sure you move any pet birds to another, closed and well- ventilated room.
  • Page 10: Cooking Guide

    Cooking guide FAN BAKE GRILL Congratulations on your new purchase. Your Fisher & Paykel oven has a number of features to make cooking a great experience for you: a wide choice of oven functions a convenient Self-Clean function – see ‘Using the Self Clean function’ intuitive controls and displays illuminated halos around the dials for visual feedback Before you start...
  • Page 11 Cooking guide BAKING For best results when baking, always pre heat your oven. The grill element may come on for a short time while the oven is heating up. The halo will turn from red to white when the preset temperature is reached.
  • Page 12: Cooking Guide

    Cooking guide BROILING This is a healthier alternative to frying. Always broil with the oven door completely shut. If you use glass or ceramic pans, be sure they can withstand the high temperatures of broiling. To avoid piercing the meat and letting juices escape, use tongs or a spatula to turn the meat halfway through cooking.
  • Page 13: Oven Functions

    Oven functions BAKE VENT BAKE Bake FAN GRILL FAN FORCED upper outer and lower elements Heat comes from both the upper and lower elements. The fan is not used in this function. Ideal for cakes and foods that require baking for a long time or at low temperatures. This function is not suitable for multi-shelf cooking.
  • Page 14 Oven functions FAN GRILL FAN FORCED PASTRY BAKE True Aero fan and rear element ROAST CLASSIC BAKE By using the central rear heating element and fan, hot air is blown into the cavity, providing a consistent temperature at all levels, making it perfect for multi-shelf cooking. Trays of cookies cooked on different shelves are crisp on the outside and chewy in the middle.
  • Page 15 Oven functions VENT BAKE FAN BAKE GRILL Maxi Broil FAN FORCED PASTRY BAKE upper inner and outer elements Intense radiant heat is delivered from both top elements. There are 9 steps between ‘Lo’ and ‘Hi’ (100% power). Preheating is not essential although some people prefer to allow the element to heat for a few minutes before they place food under the broil element.
  • Page 16: Classic Bake

    Oven functions BAKE VENT BAKE FAN GRILL FAN FORCED PASTRY BAKE Aero Pastry FAN GRILL FAN FORCED fan plus lower element ROAST CLASSIC BAKE The fan circulates heat from the lower element throughout the oven. Excellent for cooking pizza as it crisps the base beautifully without overcooking the topping. Ideal for foods such as sweet and savory pastry foods and delicate foods that require some top browning eg frittata, quiche.
  • Page 17 Oven functions this is not a cooking function Provides a constant low heat of less than 195°F / 90°C. Use to keep cooked food hot, or to warm plates and serving dishes. To Warm reheat food from cold, use another oven function to heat the food piping hot and only then change to Warm, as this function alone will not bring cold food up to a high enough temperature to kill any harmful bacteria.
  • Page 18: Cooking Charts

    Cooking Charts The recommendations in the following charts are guidelines. A lot of factors affect the exact time and temperature required for baking, roasting and broiling. Follow the instructions in your recipe or on packaging and be prepared to adjust the oven settings and cook times to achieve the best possible results for you.
  • Page 19 Cooking Charts This chart will help you to match your cooking requirements to the most appropriate cooking function. Note: Recommended method Alternative method Roasting Roast beef/pork/lamb** Roast chicken (whole) Roast chicken (pieces) Roast turkey Vegetables Broiling Steak/Chops/Cutlets Fish Ground meat patties Vegetables Toast * Some models only...
  • Page 20: Cooking Charts

    Cooking Charts Shelf True Aero (single; multi) Temp °F Temp °C Time (min) Baking American sandwich loaf - Bread 40-50 9”x5”/23x13cm loaf pan wholewheat loaf Bread 35-45 - 9”x5”/23x13cm loaf pan Cornbread 22-28 Cookies 425-450 215-230 10-12 Muffins, large 23-30 English scones 425-450 215-230...
  • Page 21 Cooking Charts Shelf Aero Bake (single; multi) Temp °F Temp °C Time (min) Baking American sandwich loaf - Bread 325-350 170-175 35-50 9”x5”/23x13cm loaf pan wholewheat loaf Bread 2 or 3 350-375 180-190 30-45 - 9”x5”/23x13cm loaf pan Cornbread 400-425 210-215 20-25 Cookies...
  • Page 22 Cooking Charts Shelf Bake (single; multi) Temp °F Temp °C Time (min) Baking American sandwich loaf - Bread 2 or 3 40-50 9”x5” /23x13cm loaf pan wholewheat loaf Bread 2 or 3 35-45 - 9”x5” /23x13cm loaf pan Cornbread 22-28 Cookies 425-450 215-230...
  • Page 23 Cooking Charts Aero Pastry Shelf Temp °F Temp °C Time (min) Baking Pastry shell 20-30 baked ‘blind’ 350 then 175 then 20-30 then bake pastry ‘blind’ then Pumpkin pie 4 then 2 30-35 add filling Baked cheesecake 55-60 (in ‘water bath’) 20-30 then bake pastry ‘blind’...
  • Page 24 Cooking Charts Maxi Broil & Broil* Shelf Broil setting Time (min) Beef Steaks - rare 8-10 Steaks - medium 6 or 7 10-15 Hamburger ground - patties 6 or 7 12-15 Lamb Chops - medium 15-20 Chops - well done 20-25 Pork Chops - well done...
  • Page 25 Cooking Charts Aero Broil Shelf Temp °F Temp °C Time (min) Beef 18-32 per rare lb/450g Boneless roast 1-4 25-40 per medium lb/ 450-1800g lb/450g 30-55 per well done lb/450g Lamb Chops - medium 6 or 7 400-440 200-225 15-20 Chops - well done 6 or 7 400-440...
  • Page 26 Cooking Charts...
  • Page 27 Cooking Charts...
  • Page 28: Automatic Cooking

    Automatic cooking You can set the oven(s) to automatically turn on later, cook for a preset time (cooking time), then automatically turn off at a preset stop time. See the example and instructions below (steps 1 to 7). If you start cooking manually and only want the oven to turn off automatically after a set cooking time: simply set the cooking time following steps 1 to 3 below and selecting a function and temperature.
  • Page 29 Automatic cooking Select function and temperature Double oven models only: To set automatic cooking for an oven - press the UPPER or LOWER selector button. Select a function. Adjust the temperature. The function halo will glow white. Press the right scroll Press the right scroll Check the clock shows button twice.
  • Page 30 Automatic cooking Set the stop time Press the right scroll button to scroll to Press the right scroll button to set the the stop time indicator. time you would like your food to be ready Press the select button to confirm. The by (ie the stop time).
  • Page 31 Automatic cooking Double oven models only: To set automatic cooking for the second oven - press the UPPER or LOWER selector button to select the second oven and repeat steps 1-7 above. When automatic cooking is set The oven and the lights will stay off, the halos will be unlit, but your oven is now set for automatic cooking.
  • Page 32: Using The Meat Probe

    Using the meat probe The meat probe is supplied with some models only. For other models it may be purchased separately. For further information or to purchase a meat probe, contact Customer Care, your authorised service centre or visit our website www.fisherpaykel.com. Using the meat probe Use your meat probe to accurately judge when your meat is perfectly cooked.
  • Page 33 Using the meat probe Press the right scroll button 4 times Use the scroll buttons to set the and the meat probe indicator will come required meat temperature (eg 167 148. on and the display will show Press the select button to confirm.
  • Page 34: User Preference Settings

    User preference settings You can set your oven to: display the temperature in degrees Celsius or Fahrenheit give audio feedback (tones and beeps) or operate quietly display time as 12-hr or 24-hr operate with the display off have its lights on or off during cooking operate in Sabbath setting (see ‘Sabbath setting’...
  • Page 35 User preference settings Press the right scroll button to scroll Press the select button to save the new through the options for that particular option . setting. Refer to the table below. For all options except ‘Display off’ : press the cancel button to quit the user preference menu.
  • Page 36: Sabbath Setting

    Sabbath setting This setting is designed for religious faiths that observe a ‘no work’ requirement on the Sabbath. While your oven is in Sabbath setting The display, dial halos and indicators will be unlit, the buttons will be unresponsive. No tones or beeps will sound. No alert codes or temperature changes will be displayed.
  • Page 37 Sabbath setting Press the scroll buttons to set the time Press the select button to activate the option. (hrs). You may set the time for up to 99 The display will flash hours. Double oven models only: Select the oven(s) you wish to use by pressing the UPPER or LOWER oven selector button Turn the function dial to Bake.
  • Page 38: Care And Cleaning

    Care and cleaning Removing and replacing the sliding shelves and side racks To remove a sliding shelf, grip it by its two front corners (making sure you are gripping the wire shelf and the sliding frame together), tilt upwards and pull it out of the oven. To remove the side racks, gently push the retaining wire from underneath the lock stud, then swing the lowest edge of the side rack up and out towards the center of the oven until the rack is almost horizontal.
  • Page 39 Care and cleaning Changing the oven light bulbs The oven is illuminated by three 12 volt/20 watt halogen bulbs. These have a very long life, but if you should need to replace one, use only a replacement bulb purchased from your nearest Fisher &...
  • Page 40: Manual Cleaning

    Care and cleaning Manual cleaning ALWAYS NEVER Before any manual cleaning or Never use a steam cleaner. maintenance, first wait for the oven to cool Never store flammable substances in the down to a safe temperature to touch, then oven. turn its power supply off at the wall.
  • Page 41 Care and cleaning Manual cleaning What? How? Important! Dials Clean with a solution of mild detergent Do not use stainless steel or oven cleaner on the dials, as doing so and hot water, then wipe dry. may damage their coating. Stainless steel Always read the label to make Clean with a solution of mild...
  • Page 42 Care and cleaning Manual cleaning What? How? Important! Meat probe Clean after every use to avoid Clean with a solution of mild detergent and hot water, then wipe contamination. dry with a microfiber cloth. Do not wash in the dishwasher, immerse in soapy water, use oven cleaner or leave in the oven during a Self Clean cycle.
  • Page 43: Using The Self Clean Function

    Using the Self Clean function During the pyrolytic Self Clean cycle the extremely high temperature burns off and breaks down grime and grease deposits. All that is left is a small amount of gray ash that you can easily remove. There is a choice of Self Clean cycles: - Self Clean (5 hours) (for normal soiling).
  • Page 44 Using the Self Clean function To start a Self Clean cycle Remove oven shelves, side racks and all other accessories, bakeware, and utensils. Wipe up any spills. Failure to do so may discolor the oven surfaces. Check the inner glass pane of the oven door. If it has soiling on it (eg stains from greasy splatter), you will need to clean it manually before starting a Self Clean cycle.
  • Page 45 Using the Self Clean function Select the Self Clean function. The display will flash Press the right scroll button once for the Self Clean cycle - the display will flash (5 hours), or Press the right scroll button a second time for the Light Self Clean cycle - the display will flash (4 hours)
  • Page 46 Using the Self Clean function When a Self Clean cycle has finished The oven will: emit a long tone automatically turn off automatically unlock the door. In a few seconds, the display will show the time of day. You need to: wait for the oven to cool down completely remove the gray ash with a small brush or damp cloth wipe out the oven with a clean damp cloth...
  • Page 47: Troubleshooting

    Troubleshooting Troubleshooting chart If there is a problem, check the chart below to see if you can fix it. If the problem cannot be fixed or persists, call your Authorized Repairer or Customer Care. Problem Possible causes What to do General The oven does not work.
  • Page 48 Troubleshooting Problem Possible causes What to do General I can feel hot air blowing This is normal. For safety reasons the cooling out of the vents after I fans will continue to run even have turned the oven off. when you have turned the function dial to ‘Off’...
  • Page 49 Troubleshooting Problem Possible causes What to do General The displays work, The oven is in ‘Demo’ mode. Call Customer Care. and the function and temperature dials halos come on but the oven does not heat up. The automatic cooking You are trying to use a meat probe You cannot use the meat probe indicators do not light up and automatic cooking.
  • Page 50 Troubleshooting Problem Possible causes What to do Self Clean function During a Self Clean This is normal: the oven’s cooling fans operate at their highest speed. cycle, the oven is louder than usual. The meat probe mode has been Ensure the meat probe is The display shows selected but the meat probe is not plugged into the socket.
  • Page 51 Troubleshooting Problem Possible causes What to do Self Clean function I have canceled a Self This is normal: if the function dial Wait until the cool-down phase Clean cycle but cannot halo is unlit, you have has finished. A long tone will use the oven: successfully canceled the sound and the oven door will...
  • Page 52: Alert Codes

    Alert codes If there is a problem, the oven will: automatically suspend all oven functions beep five times display an alert code. Important! Do not turn off the mains power supply to the oven (wall switch) if you get an alert code, unless the instructions in the chart following specifically instruct you to.
  • Page 53 Alert codes Alert code Possible causes What to do The oven has overheated. Allow the oven to cool down. Once the oven has cooled down and the door has unlocked, the alert code will disappear. You can now use the oven again.
  • Page 54: Warranty And Service

    Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: your product is correctly installed. you are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &...
  • Page 56 www.fisherpaykel.com Copyright © Fisher & Paykel 2014. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
