GE ApexPro Service Manual page 25

ATS block diagram
CD ROM IDE
To CN19 of RSM
Soft Power and
System Reset Switchs
CN21 CN18
CN19 CN29
CN17
CN16
CN14
Not Used
to Auxiliary
Power Supply
Front Ethernet
Port
Intel
Ethernet
Card
Front HDD LED
Redundant ATX
Power Supply
Unit (PSU)
300W Peak
From SBC CN18 System Reset Signal and CN21 Soft Power Signal
2001989-203C
Directs and controls ApexPro operations including EK-Pro, trends, histories,
ECG processing and alarms.
Stores data to the ATS hard drive.
Assigns/associates receiver and TTX numbers during patient admit.
Sends data via the Unity Network MC network to the CIC Pro center for patient
data display.
NOTE
The ApexPro host software application does not provide user accessible
functions, but instead relies on remote user interfaces, such as the CIC Pro
center. Refer to the CIC Pro center documentation for further information.
Memory
DRAM 512Mb
ATA ribbon cable
CN1
CN2
DIMM1
CPU fan
DIMM2
Single Board Computer (SBC)
CPU
Advantech PCA-6184E2-00A2
Pentium 4
Power Supply On Signal
ISA1 slot
PICMG1 slot
ATX1
CN2
PCI Backplane
PCI slot 2
PCI slot 3
PCI slot 4
Promise Technology, Inc
SATA RAID
Controller Card
J2
IDE1
SATA cable
Top Primary
3.5" Hard Drive
Bottom Secondary
3.5" Hard Drive
Front Soft
Power Switch
Front System Reset Switch
ApexPro Telemetry Server
NOTE
Representational only. Drawing does not show exact location of cards or
connectors.
ApexPro™ Telemetry
CN3
CN4
CN10
J1
J2
Bottom
CN22
CN8
CN13
To CN20 of
RSM
To Riser Card
Watch dog timer
Voltage from Backplane
Temp Sensor 2
Front by fans
From J2 of SBC
Watch dog timer
Temp Sensor 3
Hard Drive Cage
Internal
JP2
J1
Serial Port
to COM2 of
Temp Sensor 1
SBC Near Power
Supply Cage
SATA cable
SM Bus
Back Ethernet
Port
CN1
External
Buzzer
Equipment overview
Two Front
USB Ports
Internal
Top
Serial Port
COM2 to RSM
Bottom
Serial Port
COM1
LAN 2
Ethernet
Port to RX
VGA
Video Port
PS/2 mouse
& keyboard
Front Keyboard
Riser Card with Rear Panel Connections
CN1
TS3
From ATX PSU
CN2
Power Fail Signal
Chassis fan #1
CN1
TS1
CN2
FAN1 FAN2 FAN3
CN4 CN13
CN16
SNMP/HTTP
CN19 Remote System Manager (RSM)
J1
J1
Kernal Module
CN17
FAN7
CN18 CN10
Front Power, Temp & Fan LEDs
Ethernet
Port to IX
Chassis fan #2
Front Alarm
Reset Switch
005A
2-9
