Ipevo Ziggi-HD Plus Quick Start Manual

USB Document Camera
Quick Start Guide
Customer Service (USA) Customer Service (International)
Email: cs@ipevo.com Email: service@ipevo.com
Tel: +1-408-490-3085 Tel: +886-2-5550-8686
Ziggi-HD Plus captures a variety of subjects—including standard letter-sized
The Basics
documents, three-dimensional objects, devices like smartphones and Apple's iPad,
and even A3-sized documents and larger—and presents a high-definition live video
image through the Presenter software.
Positioning the Ziggi-HD Plus
The multi-jointed, weighted stand allows you to quickly and easily change the
height and position of the camera to suit your subject.
Additionally, the camera head can swivel with 270° of freedom to customize your
orientation.
Package Contents
Your package should contain the following:
• Ziggi-HD Plus camera unit, including multi-jointed stand.
• Anti-Glare Shield.
• Quick Start Guide (this document).
Note: The Complete User Manual can be downloaded at http://support.ipevo.com/ziggi-hd-plus
Ziggi-HD Plus requires IPEVO Presenter software to function.
Installation
Please download the latest version for PC or Mac at:
http://support.ipevo.com/presenter
1.Double-click the downloaded file and follow the prompts to install Presenter.
Note: By installing the latest version of Presenter, the older version of Presenter on your
computer will be removed or replaced.
2.Connect Ziggi-HD Plus's USB cord to any open USB port on your computer.
3.Launch the Presenter software. A window containing a live video image from
your Ziggi-HD Plus should appear. Ziggi-HD Plus is now ready to use.
Camera
Elements
1. Focus button: will bring the subject into sharp focus after a few seconds.
2. Autofocus switch: may be set to Single (S) or Continuous (C).
3. Exposure toggle: provides on-the-fly exposure customization.
4. Camera indicator: when the camera is in use with IPEVO Presenter or other
compatible software to provide an image, this will turn white.
5. Microphone: Ziggi-HD Plus comes with a built-in microphone which is located
on the underside of the camera body next to the lens. The microphone is on
when Ziggi-HD Plus is on. This is useful for video conferencing and more.
