- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation K1 Series Dual Display Column Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description K1C250...
-
Page 2: Installation Instructions
It is the installer’s responsibility to make sure the combined weight of all components located between the K1C250 Monitor Arm up to (and including) the display does not exceed 25 lbs (11.34 kg) per arm. Use with products heavier than the maximum weight indicated may result in collapse of the mount and its accessories causing possible injury. - Page 3 Installation Instructions K1C250 DIMENSIONS...
- Page 4 K1C250 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions K1C250 TOOLS REQUIRED FOR INSTALLATION 3/16" (included) 1/8" (included) PARTS A (1) [K1C250 assembly] B (8) D (8) C (8) M4x14mm M10x5.3x10 M4x25mm F (1) E (1) 1/8" 3/16"... -
Page 6: Display Installation
It is the installer’s responsibility to make sure the combined weight of all components located between the K1C250 Monitor Arm up to (and including) the display does not exceed 25 lbs (11.34 desk kg) per arm. - Page 7 Installation Instructions K1C250 For recessed mounting hole installation: Pivot Adjustment • Place four spacers (D) on top of mounting holes on Adjust pivot position as desired. (See Figure 7) back of display. (See Figure 5) Use 3/16" hex key (E) to adjust pivot point tension screws to •...
-
Page 8: Cable Management
K1C250 Installation Instructions Pivot Adjustment Range Cable Management Adjust arm angles as desired within a 90 degree range from Use screwdriver to unhinge tab on either end of cable the edge and a perpendicular centerline of mount. (See management cover on upper arm. (See Figure 10) -
Page 9: Display Removal
Installation Instructions K1C250 Display Removal WARNING: Only remove display from mount when the display can be lifted up from the mount! DO NOT remove display unless the display is in the upright position! (See Figure 12) Make sure display is in the upright position. - Page 10 K1C250 Installation Instructions...
- Page 11 Installation Instructions K1C250...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
