I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Height-adjustable Grommet Monitor Arms
K1C1KRA204
K1C1KRA204-K1C2KRA204
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
K1C2KRA204
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CHIEF K1C1KRA204
Summary of Contents for CHIEF K1C1KRA204
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation K1C1KRA204 K1C2KRA204 Height-adjustable Grommet Monitor Arms Spanish Product Description German Product Description Portuguese Product Description Italian Product Description...
-
Page 2: Installation Instructions
Do not use this product outdoors. no responsibility for accuracy, completeness or sufficiency of the information contained in this document. --SAVE THESE INSTRUCTIONS!-- Chief® is a registered trademark of Milestone AV Technologies. All rights reserved. IMPORTANT SAFETY INSTRUCTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. - Page 3 Installation Instructions K1C1KRA204-K1C2KRA204 DIMENSIONS K1C1KRA204 8.84 4.77 PITCH RANGE 10 DOWN 3.80 MIN 21.10 MAX EXTENSION QUICK RELEASE INTERFACE VESA INTERFACE ROTATION 20.00 MAX 7.00 MIN ARM HEIGHT ADJUSTMENT 10.75 MANUAL HEIGHT ADJUSTMENT RANGE HEIGHT ADJUSTMENT KNOB 2.00 .75 MIN 4.00 MAX...
- Page 4 K1C1KRA204-K1C2KRA204 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
A (1) [K1C2OFB215 assembly] C (4 or 8)* B (4 or 8)* D (4 or 8)* M4x25mm M4x14mm M10x5.3x10 * 4 for K1C1KRA204, 8 for K1C2KRA204 F (1) E (1) 5/16-18 x 5" [grommet bracket] G (5) J (1) H (1) [rubber feet] 1/8”... -
Page 6: Display Installation
K1C1KRA204-K1C2KRA204 Installation Instructions Assembly And Installation Display Installation Remove quick release faceplate from mount by pressing Assembly to Desk quick release tab and sliding faceplate off mount. (See Figure 3) Affix five rubber feet (G) to underside of column plate of assembly (A). - Page 7 Position display with faceplate attached above mount. (See to change pivot adjustment tension. (See Figure 7) Figure 6) Slide faceplate onto mounting head until quick release tab clicks into place. (See Figure 6) (K1C1KRA204 shown) Reduce tension (lighter display) Increase tension (heavier display)
-
Page 8: Cable Management
Adjust height to desired level. (See Figure 8) Slide screwdriver along edge of cover until remaining tabs Tighten column adjustment knob. (See Figure 8) are unhinged and cover is in the “open” position. (See Figure 10) (K1C1KRA204 shown) cable management cover Figure 10 Figure 8 Portrait Adjustment The monitor may be adjusted 90 degrees in either direction in order to provide a portrait view of the monitor. -
Page 9: Display Removal
Installation Instructions K1C1KRA204-K1C2KRA204 Display Removal WARNING: Only remove display from mount when the display can be lifted up from the mount! DO NOT remove display unless the display is in the upright position! (See Figure 12) Make sure display is in the upright position. - Page 10 K1C1KRA204-K1C2KRA204 Installation Instructions...
- Page 11 Installation Instructions K1C1KRA204-K1C2KRA204...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
