Service Manual

MOBILE THERMAL PRINTER
CMP-20
MODEL
Rev. 1.02 Issued on January 2013
With CSE Part Numbers.

Advertisement

loading

Related Manuals for Citizen CMP-20

Summary of Contents for Citizen CMP-20

  • Page 1: Service Manual

    Service Manual MOBILE THERMAL PRINTER CMP-20 MODEL Rev. 1.02 Issued on January 2013 With CSE Part Numbers.

  • Page 2: Revision History

    CMP-20 Service Manual REVISION HISTORY REVISION DATE APPROVAL CHANGE 07 / 01 / 2010 Initial Release 01 / 10 / 2010 Use CSE Part Numbers 24 / 01 / 2013 Minor correction...

  • Page 3: Table Of Contents

    CMP-20 Service Manual TABLE OF CONTENTS REVISION HISTORY ................... 3 TABLE OF CONTENTS ..................4 1. Disassembly and Assembly ................5 2. Parts List ......................6 3. Circuit Diagram ....................24...

  • Page 4: Disassembly And Assembly

    CMP-20 Service Manual 1. Disassembly and Assembly 1. How to Separate Lower Housing 1-1) Unfasten 4 screw as shown in the figure and separate the Lower Housing 2. How to separate Upper Housing 2-1) Disassemble it as indicated way 3. Separate Paper Tray 3-1) Unfasten 4 screw as shown in the figure and separate the Paper Door 4.

  • Page 5: Parts List

    CMP-20 Service Manual 2. Parts List PARTS LIST CMP-20 TOTAL EXPLODE VIEW Symbol Parts No. Description Q’ty Remarks PM20AS-B005 LOWER HOUSING ASM (1-1) TB 2.6 X 10 SCREW (1-2) M 2.6 X 20 SCREW (1-3) PM20MD-C008 NECK HOOK PM20AS-B004 UPPER HOUSING ASM (2-1) TB 2.6 X 6...
  • Page 6 CMP-20 Service Manual EXPLODE VIEW TOP COVER ASM PARTS LIST CMP-20 EXPLODE VIEW Symbol Parts No. Description Q’ty Remarks PM20MD-C003 TOP COVER PM20MD-C005 WINDOW MECHNISM ASSEMBLY INCLUDING PM20DG-C001 PLATTEN ROLLER TB 2.6 X 5 PH SCREW BLACK...
  • Page 7 CMP-20 Service Manual EXPLODE VIEW...
  • Page 8 CMP-20 Service Manual PAPER TRAY ASM PARTS LIST CMP-20 EXPLODE VIEW Symbol Parts No. Description Q’ty Remarks PM20MD-C004 PAPER TRAY PM20DG-C002 MSR ASSEMBLY OPTION MECHNISM ASSEMBLY INCLUDING PM20DG-C001 PLATTEN ROLLER PM20PS-C002 LIFT SPRING PM20CT-C002 CABLE SPACER PM20WH-C001 CABLE GND PM20CT-C003...
  • Page 9 CMP-20 Service Manual EXPLODE VIEW IC CARD FRAME ASM PARTS LIST CMP-20 EXPLODE VIEW Symbol Parts No. Description Q’ty Remarks PM20MD-C006 IC CARD FRAME PCB BLUETOOTH PM20DG-C003 Or PCB WIFI PM20DG-C003 PCB IC CARD ASSEMBLY TB 2.0 X 6 SCREW...
  • Page 10 CMP-20 Service Manual EXPLODE VIEW...
  • Page 11 CMP-20 Service Manual UPPER HOUSING ASM PARTS LIST CMP-20 EXPLODE VIEW Symbol Parts No. Description Q’ty Remarks PM20MD-C002 UPPER HOUSING PM20MD-C021 KEY POWER PM20MD-C019 LENS LED PM20MD-C020 KEY FEED PM20PA-B004 PCB FUCNTION ASSEMBLY TB 2.0 X5 SCREW PM20PS-C005 BRACKET TEAR BAR TB 2.0X3 납작...
  • Page 12 CMP-20 Service Manual EXPLODE VIEW...
  • Page 13 CMP-20 Service Manual LOWER HOUSING PARTS LIST CMP-20 EXPLODE VIEW Symbol Parts No. Description Q’ty Remarks PM20MD-C002 LOWER HOUSING PM20PA-B001 PCB MAIN ASSEMBLY TB 2.0 X 8 SCREW 2000435 BATTERY ASSEMBLY PM20MD-C009 BELT HOOK M 4.0*10 SN BH SCREW...
  • Page 14 CMP-20 Service Manual EXPLODE VIEW...
  • Page 15 CMP-20 Service Manual PARTS LIST CMP-20 PACKING Symbol Parts No. Description Q’ty Remarks PM20PK-C001 TOP CASE PM20PK-C002 BOTTOM CASE PM20PK-C003 UNIT BOX MASTER BOX PM20PK-C001 CMP-20 TOTAL ASS’Y CABLE SERIAL MINI DIN PM20WH-C005 PM20WH-C001 CABLE USB CMP-20 PM20PK-C001 MANUAL ; CD...
  • Page 16 CMP-20 Service Manual PARTS LIST CMP-20 MAIN PCB Symbol Parts No. Description Q’ty Remarks PM20BP-C001 STR710RZF2T6 K6X4016V1C/44 SST39VF1601-70-4C-EKE A3906 U9,U11,U12 SN74LVC04 SN74LVC08 SP3232 TPCS81111 S-8521 48MHZ OSC 16MHZ OSC S-80930C-G9FT2G QT1,Q4,Q7,Q8 SUT485J S Q6,Q9 FJX3904 KTA1663(SOT-89) KDS160 DIODE SS16 DIODE...
  • Page 17 CMP-20 Service Manual PARTS LIST CMP-20 MAIN PCB Symbol Parts No. Description Q’ty Remarks 5.6K RESISTOR CHIP RESISTOR CHIP RESISTOR CHIP RESISTOR CHIP 3.3K RESISTOR CHIP 1.5K RESISTOR CHIP RE14,R6 RESISTOR CHIP RS14,R29 RESISTOR CHIP RR1,RE2,RE16 RESISTOR CHIP RM3, RM4 0.75Ω...
  • Page 18 CMP-20 Service Manual...
  • Page 19 CMP-20 Service Manual PARTS LIST CMP-20 BLUETOOTH PCB Symbol Parts No. Description Q’ty Remarks PM20PA-B101 PM20SH-C101 PM20PB-C101 PM20PB-C101 PCB REV 54(1.0T) MD-4DR MODULE ANT1 AMAN1130 R1-R5 RESISTOR CHIP RESISTOR CHIP C3,C4,C5,C6,CE1 0.1uF CAPACITOR CHIP SS16 DIODE 12513WR-08A CONNECTOR WAFER...
  • Page 20 CMP-20 Service Manual...
  • Page 21 CMP-20 Service Manual PARTS LIST CMP-20 Wireless Symbol Parts No. Description Q’ty Remarks PM20PB-C201 WM001 MODULE AT91SAM7X512 IC CPU ELM88181BA(SOT-23) IC REGULATOR TXB0108(TSOP20) IC LEVEL SHIFTER 48MHZ OSC 11.0592MHz CRYSTAL FJX3904 ANT1 AMAN1130 100Ω RESISTOR CHIP RA1,R30 150Ω RESISTOR CHIP...
  • Page 22 CMP-20 Service Manual...

  • Page 23: Circuit Diagram

    CMP-20 Service Manual 3. Circuit Diagram...
  • Page 24 CMP-20 Service Manual...
  • Page 25 CMP-20 Service Manual...
  • Page 26 CMP-20 Service Manual...
  • Page 27 CMP-20 Service Manual...
