Mobile Printer

CMP-40
Windows Driver Manual
VER.1.00
6-1-12 Tanashi-cho, Nishi-Tokyo-shi, Tokyo 188-8511
JAPAN
Tel 81-424-68-4631
Fax 81-424-68-4740
sales-op@systems.citizen.co.jp
http://www.citizen-systems.co.jp

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMP-40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Citizen CMP-40

Summary of Contents for Citizen CMP-40

  • Page 1: Mobile Printer

    Mobile Printer CMP-40 Windows Driver Manual VER.1.00 6-1-12 Tanashi-cho, Nishi-Tokyo-shi, Tokyo 188-8511 JAPAN Tel 81-424-68-4631 Fax 81-424-68-4740 sales-op@systems.citizen.co.jp http://www.citizen-systems.co.jp...
  • Page 2 All other company names or product names are the trademarks or registered trademarks of their respective holders. CITIZEN is a registered trade mark of CITIZEN WATCH CO., LTD., Japan CITIZEN es una marca registrada de CITIZEN WATCH CO., LTD., Japón...

  • Page 3: Table Of Contents

    CMP-40 Windows Driver Index 1. About This Document .......................... 3 2. Support OS ............................3 3. Driver Installation..........................3 3-1 Preparation of Driver Installation ...................... 3 3-2 Installation for USB interface ......................4 3-3 Installation for Serial or Bluetooth interface ..................7 3-4 Serial Port Setting ..........................

  • Page 4: About This Document

    And latest driver can be downloaded from our web site as well. If the interface is Bluetooth, Serial or WLAN, check the COM port or TCP/IP address before starting driver installation. If the interface is serial, check the serial port setting of CMP-40 by self-printing. Run the driver installer file “CITIZENCMP-40PrinterDriver1.xx.exe”.

  • Page 5: Installation For Usb Interface

    CMP-40 Windows Driver 3-2. Installation for USB interface Before connecting printer, run “CITIZENCMP-40PrinterDriver1.xx.exe” to start driver installation. Check the model (emulation) to install driver and press “Installation”. If necessary, you can install both drivers together. If you use USB interface for the driver, choose USB from “Printer Port” drop-down menu and press “OK”.
  • Page 6 CMP-40 Windows Driver When you see the message below, connect printer to the PC, turn the printer on and press “OK”. - 5 -...
  • Page 7 CMP-40 Windows Driver If you see the message below, choose “Install this driver software anyway”. When the message below appears, installation is finished. Please check if you can see the CMP-40 driver in “Devices and Printers” - 6 -...

  • Page 8: Installation For Serial Or Bluetooth Interface

    CMP-40 Windows Driver 3-3 Installation for Serial, Bluetooth or WLAN interface Beginning procedures are same as USB. Choose the COM port for serial or Bluetooth. If interface is WLAN, choose TCP/IP. If you choose COM port, you see the message below.
  • Page 9 CMP-40 Windows Driver Last steps of installation procedure are same as USB. - 8 -...

  • Page 10: Serial Port Setting

    CMP-40 Windows Driver 3-4 Serial Port Setting For Serial port, you may need to change port setting. In “Devices and Printers”, choose CMP-40 drive icon and right-click. Then choose “Printer properties”. Choose ”Port” tab and press “Configure Port”. - 9 -...
  • Page 11 CMP-40 Windows Driver You can change the Bits per second (Baud rate), Data bits, Parity, Stop bits, and Flow control here. - 10 -...

  • Page 12: Uninstallation Of Driver

    CMP-40 Windows Driver 4. Driver Uninstallation Move to “C:\CMP-40 1.X” folder and run “DriverUninstaller.exe”. or you can do the same from “Uninstall a program”. Choose the driver to uninstall and press “Uninstallation(D)”. (You can uninstall both drivers altogether.) When you see the message below, press OK to complete the uninstallation.

  • Page 13: Driver For Receipt (Esc/Pos)

    CMP-40 Windows Driver 5. Driver for Receipt (ESC/POS) 5-1. Driver Function 5-1-1. Printer Commands You can add command to the top/bottom of print data generated by the driver. “Begin Document” is added to the top of print data. “End Document” is added to the bottom of print data.
  • Page 14 CMP-40 Windows Driver 5-1-2. Print Order You can change the order of printing pages for multiple pages or multiple copies printing. If you want reverse order, click ”Reverse Print Order”. - 13 -...
  • Page 15 CMP-40 Windows Driver 5-1-3. Print Orientation and Adjusting Printing Size This tab allows following function. Choosing paper size, defining own paper size, choosing page orientation and adjusting printing size. - 14 -...
  • Page 16 CMP-40 Windows Driver 5-1-4. Barcode You can define barcode type, size and HRI setting for Font name Barcode1 through Barcode8. - 15 -...
  • Page 17 CMP-40 Windows Driver 5-1-5. 2D Code You can define 2D barcode type, module size, column number, error correction level to the Font name 2D- Code1 through 2D-Code8. - 16 -...
  • Page 18 CMP-40 Windows Driver 5-1-6. Logo Printing Two ways of logo printing are supported. One is printing logo data registered in NV memory. The other one is printing BMP file. For the timing of logo printing, Start/End of Document or Start/End of page can be selected.
  • Page 19 CMP-40 Windows Driver 5-1-7. Water Mark Choose the bitmap file for watermark and specify the printing position, density and size. - 18 -...
  • Page 20 CMP-40 Windows Driver 5-1-8. Coupon Printing This is similar function as BMP file logo printing or water mark printing. Choose BMP file, dithering type, vertical printing position, density and size. - 19 -...
  • Page 21 CMP-40 Windows Driver 5-1-9. Replacing Text The text in the print data can be replaced with other text by this function. There are limitations to use this function. - 20 -...
  • Page 22 CMP-40 Windows Driver 5-1-10. ControlA You can define command sequence to any character of controlA device font and when the character is printed as controlA, the command is executed instead of printing. For example, WordPad on old version Windows allows to use controlA as font. Font size is 8.5.
  • Page 23 CMP-40 Windows Driver Then command data is defined. - 22 -...

  • Page 24: Driver Device Font

    CMP-40 Windows Driver 5-2. Driver Device Font 5-2-1. Font for Characters This driver supports following device font for character printing. Using this function, printing is much faster than graphic printing. There are limitations to use these fonts. Font name Size(Dot)
  • Page 25 CMP-40 Windows Driver 5-2-3. Font for Special Function You can use special function by printing following character using “control” font. Each character will not be printed. Font size of “control” is 8.5. Character Function Horizontal tab (HT) Line feed (LF)

  • Page 26: Logo Utility

    CMP-40 Windows Driver 5-3. Logo Utility Logo utility appears as mentioned in section 5-1-6 “Logo Printing”. You can also move to “C:\CMP-40 1.x” folder and run CMPLogo.exe to call this utility. - 25 -...

  • Page 27: Driver For Cpcl (Label)

    CMP-40 Windows Driver 6. Driver for CPCL (Label) 6-1. Driver Function 6-1-1. Page Setup Function of this tab New page size can be created here. 180 degrees rotate printing can set here. 2 columns or 3 columns printing can be chosen by N-up Function.
  • Page 28 CMP-40 Windows Driver New page size By pressing “Add” or “Edit”, the dialogue below appears. You can enter the size here. - 27 -...
  • Page 29 CMP-40 Windows Driver 6-1-2. Media Setup This tab allows following settings. Print Media (Label with Gap/Label with mark/Continuous) Print Speed (Current Setting, Speed 0 through Speed 5) Density (Current Setting, Density 0 through 3 Back feed before print (No, Yes).
  • Page 30 CMP-40 Windows Driver 6-1-3. Barcode Font Setup Choose the Barcode font from the list and press “Modify”. Then set the barcode Choose type of barcode on Symbology. - 29 -...

  • Page 31: Driver Device Font

    CMP-40 Windows Driver 6-2. Driver Device Font 6-2-1. Font for Characters This driver supports following device font for character printing. Using this function, printing is much faster than graphic printing. There are limitations to use these fonts. Font name Size...
