LMP-0600 Series User Manual V1.0
LMP-0600 Series
6-Port Industrial PoE+ Managed Ethernet Switches
4*10/100Tx (30W/Port), 2*10/100Tx, 48~55VDC Power Input

User Manual

Version 1.0
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMP-0600 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ANTAIRA LMP-0600 Series

Summary of Contents for ANTAIRA LMP-0600 Series

  • Page 1: User Manual

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 LMP-0600 Series 6-Port Industrial PoE+ Managed Ethernet Switches 4*10/100Tx (30W/Port), 2*10/100Tx, 48~55VDC Power Input User Manual Version 1.0...
  • Page 2 Trademark Information Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA are the registered trademarks of Wi-Fi Alliance.

  • Page 3: Fcc Warning

    Industrial Grade Gigabit Unmanaged Ethernet Switches User Manual Version 1.0 (September 2014) This manual supports the following models:  LMP-0600  LMP-0600-T This document is the current official release manual. Please check our website (www.antaira.com) for any updated manual or contact us by e-mail (support@antaira.com).

  • Page 4: Table Of Contents

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Table of Contents 1. Introduction....................1 1.1 Product Overview ................1 1.2 Product Software Features ............1 1.3 Product Hardware Features ............2 1.4 Package Contents ................. 2 1.5 Safety Precaution ................3 2.
  • Page 5 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.3.1 Port Status ................18 5.3.2 Port Configuration ..............18 5.4 PoE (Power-over-Ethernet) ............19 5.4.1 PoE Configuration ..............19 5.4.2 Ping Alarm ................20 5.4.3 PoE Schedule ................ 21 5.5 ERPS ................... 22 5.5.1 ERPS Status ................
  • Page 6 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.11.1 SNMP Agent ................. 44 5.11.2 SNMP Trap setting ............... 45 5.12 System Warning ................. 46 5.12.1 Syslog Setting ..............46 5.12.2 System Event Log ..............47 5.12.3 SMTP Setting ............... 48 5.12.4 Event Selection ..............

  • Page 7: Introduction

    (SNMP). 1.1 Product Overview Antaira’s LMP-0600 series is a 6-port industrial PoE+ managed Ethernet switch that is IEEE 802.3at complaint (power-over-Ethernet plus), and is embedded with four 10/100Tx Ethernet ports that support either IEEE802.3af or IEEE802.3at for a maximum of 30 watts per port, and two 10/100Tx Fast Ethernet ports.

  • Page 8: Product Hardware Features

    Installation in pollution degree to environment  DIN-Rail and wall mount design 1.4 Package Contents  1– LMP-0600 series: 6-port industrial PoE+ managed Ethernet switch, with 4*10/100Tx (30W/Port) RJ45 Ports, and 2*10/100Tx Fast Ethernet ports.  1-Product CD  2-Wall mounting brackets and screws ...

  • Page 9: Safety Precaution

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0  1-DC cable –18 AWG & DC jack 5.5x2.1mm 1.5 Safety Precaution Attention: If the DC voltage is supplied by an external circuit, please use a protection device on the power supply input. The industrial Ethernet switch’s hardware specs, ports, cabling information, and wiring installation will be described within this user manual.

  • Page 10: Hardware Description

    LMP-0600 Series User Manual V1.0 2. Hardware Description 2.1 Physical Dimensions Figure 2.1, below, shows the physical dimensions of Antaira’s LMP-0600 series: 6-port industrial PoE+ managed Ethernet switch with 4*10/100Tx (30W/Port) RJ45 ports, and 2*10/100Tx RJ45 ports. (W x D x H) is 46mm x 99mm x 142mm Figure2.1...

  • Page 11: Front Panel

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 2.2 Front Panel The front panel of the LMP-0600 series industrial PoE+ managed Ethernet switch is shown below in Figure 2.2. Figure2.2 The Front Panel of LMP-0600 Series 2.3 Top View Figure 2.3, below, shows the top panel of the LMP-0600 series switch that is equipped with...

  • Page 12: Led Indicators

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 2.4 LED Indicators There are LED light indicators located on the front panel of the industrial Ethernet switch that display the power status and network status. Each LED indicator has a different color and has its own specific meaning, see below in Table 2.1.
  • Page 13 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0  RJ-45 Pin Assignments (Table 2.2) Pin Number Assignment Table 2.2 RJ45 Pin Assignments “+” and “-” signs represent the polarity of the wires that make up each wire pair. Note All ports on this industrial Ethernet switch support automatic MDI/MDI-X operation.

  • Page 14: Cabling

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 2.6 Cabling  Twisted-pair segments can be connected with an unshielded twisted pair (UTP) or shielded twisted pair (STP) cable. The cable must comply with the IEEE 802.3u 100Base TX standard (e.g. Category 5, 5e, or 6). The cable between the equipment and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long.

  • Page 15: Wiring The Fault Alarm Contact

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 2.8 Wiring the Fault Alarm Contact The fault alarm contact is in the middle of the terminal block connector as the picture shows below in Figure 2.8. By inserting the wires, it will detect the fault status including power failure or port link failure (managed industrial switch only) and forma normally open circuit.

  • Page 16: Mounting Installation

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 3. Mounting Installation 3.1 DIN-Rail Mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-Rail on the switch.

  • Page 17: Wall Mounting

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 3.2 Wall Mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown below in Figure 3.4. 1. Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws.

  • Page 18: Hardware Installation

    LMP-0600 Series User Manual V1.0 4. Hardware Installation 4.1 Installation Steps This section will explain how to install Antaira’s LMP-0600 series: 6-port industrial PoE+ managed Ethernet switch with 4*10/100Tx (30W/Port) RJ45 ports and 2*10/100Tx RJ45 ports. Installation Steps 1. Unpack the industrial Ethernet switch from the original packing box.

  • Page 19: Web Management

    This section introduces the configuration by web browser. 5.1.1 About Web-Based Management All of Antaira’s industrial managed switches are embedded with HTML web console interfaces that have a flash memory on the CPU board. It is a “user friendly” design with advanced management features that allow users to manage the switch from anywhere on the network through any Internet browser, such as Internet Explorer (version 9.0 or above is recommended),...

  • Page 20: Basic Setting

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 3. The login screen appears 4. Key in the default username: admin and password: admin 5. Click “Login” button, then the main (status) page of the web console will appear as below in Figure 5.2.

  • Page 21: Admin &Password

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Terms Value Description Factory Default: Switch *User can assign any name label to identify this managed node. By convention, a domain name is a text string drawn from the System Name alphabet (A-Z, a-z), digits (0-9), minus sign (-).

  • Page 22: Ip Setting

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Terms Value Description New Password User can assign a New Password, and the maximum allow string length is 0 to 31 characters. Confirmation Re-type the new password. Click “Apply” to save changes.

  • Page 23: System Time

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Subnet Mask Assign the subnet mask of the IP address. If DHCP client function is enabling, user does not require to assign the subnet mask Gateway Assign the network gateway for the switch. If DHCP client function is enabling, user does not require to assign the Gateway.

  • Page 24: Port Management

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.3 Port Management 5.3.1 Port Status The following information provides the current port status. Figure 5.11 – Port Status Interface 5.3.2 Port Configuration Users can assign or insert a “value/label” for each port under each “Port Name” box; enable or disable each port function;...

  • Page 25: Poe (Power-Over-Ethernet)

    Figure 5.13 – Port Configuration Description 5.4 PoE (Power-over-Ethernet) LMP-0600 series is one of Antaira’s industrial PoE+ managed switches that has four built-in IEEE802.3at complaint ports, and each PoE port can support PoE output power up to a maximum of 30W per port. It is also backward compatible with IEEE 802.af to support any standard PoE powered devices (PD).

  • Page 26: Ping Alarm

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Terms Value Description Port No. PoE Port Number Any PoE port will automatically detect any powered device that is Status connected and will display the situation. Users can use the dropdown box to enable or disable any PoE port...

  • Page 27: Poe Schedule

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.4.3 PoE Schedule For energy saving or power recycle powered devices, the PoE managed switch’s PoE schedule interface allows users to appoint any date and time to enable or disable PoE functions for each PoE port.

  • Page 28: Erps

    Antaira is proud to introduce and implement Ethernet Ring Protection Switching (ERPS) protocol as a standard ring solution for network redundancy with all new industrial managed Ethernet switches.

  • Page 29: Erps Status

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.5.1 ERPS Status Below, Figure 5.18, shows the network redundancy ring status with the Ethernet Ring Protection Switch (ERPS) protocol. Figure 5.18 – Redundant Ring Network – ERPS Status 5.5.2 ERPS Configuration Below, Figure 5.19, shows the ERPS configuration interface.
  • Page 30 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Terms Value Description “Enable” or “Disable” ERPS protocol Protocol ERPS ring port 0, it could be map to real switch port 1 – port 6. Ring Port 0 Do not set the same as Ring port 1.
  • Page 31 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.5.2.1 Scenario A – RPL configured Architecture Under this scenario A, there are three major roles that are required in order to be configured within the ERPS configuration. Figure 5.21 – RPL-Configured Architecture...
  • Page 32 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Figure 5.22 – RPL Owner Node Setup Example By selecting “Yes” under the “Revertive” mode, the ring will recover the ring’s state from ABNORMAL to NORMAL within 5 minutes. Otherwise, the blocked port will remain blocked permanently until the user re-configures it.
  • Page 33 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Figure 5.23 – RPL Neighbor Node Setup Example [Normal Node] Then user should setup the rest of the managed switches’ “Role” of both “Ring Port 0 and 1” as “Normal Node” as shown above in Figure 5.23. Please be sure no duplicate port number has been chosen within a managed switch’s ERPS ring setting, the incorrect configurations...
  • Page 34 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Figure 5.24 – RPL Normal Node Setup Example 5.5.2.2 Scenario B – Non-Configured Architecture In some situations, users can choose not to configure the RPL owner and neighbor node; the ERPS could still work well under the mechanism by blocking one of the ring ports in the ERPS...
  • Page 35 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Figure 5.25 – Non-Configured Architecture As shown above in Figure 5.25, the ERPS is blocked at one of the ring node ports. The blocked port is chosen by an election mechanism that is decided by the MAC address. Because the MAC address is unique, the ERPS will just choose the biggest MAC as the blocking node.

  • Page 36: Spanning Tree

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Figure 5.26 – Non-Configured Architecture Setup example 5.6 Spanning Tree The Spanning Tree Protocol (STP), defined in the IEEE Standard 802.1d, can be created within a mesh network of connected layer-2 switches.

  • Page 37: Rstp Status

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.6.1 RSTP Status Figure 5.27 shows the RSTP algorithm results. Figure 5.27 – RSTP Information Interface 5.6.2 RSTP Configuration Users can enable/disable the RSTP function, and set the parameters for each port.
  • Page 38 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Terms Value Description User can select RSTP or MSTP function to be enabled or Mode disabled before configuring the related parameters. A value used to identify the root bridge. The bridge with...

  • Page 39: Msti Status

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 The port includes the STP mathematic calculation. Admin Non STP True is not including STP mathematic calculation. False is including the STP mathematic calculation. Click “Apply” button to save changes. Figure 5.29 – RSTP Configuration Terms & Value Description MSTP (Multiple Spanning Tree Protocol) It is defined in IEEE 802.1s, it can map a group of VLAN’s into a single multiple spanning tree...

  • Page 40: Msti Configuration

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.6.4 MSTI Configuration Users can display the MSTI root status and port status by selecting the “Instance ID” number from 1 to 15 by clicking on the dropdown box from the “MSTI Status” interface.
  • Page 41 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Click “Apply” button to save changes. Figure 5.32 – MSTI Configuration –Terms & Value Description Figure 5.33 – MSTI Port Configuration Interface Terms Value Description Users can select Instance Tab #1~#15 to configure each Instance Tabs MSTI port “Cost”...

  • Page 42: 802.1Q Vlan

    PVID. All of Antaira’s industrial managed switches’ have a default VLAN setting set to “none” for each port, so the users can login to the VLAN setting interface to create a VLAN Group name and choose “Tag”...

  • Page 43: 802.1Q Vlan Settings

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.7.2 802.1Q VLAN Settings Figure 5.36 – 802.1Q VLAN Settings Interface Terms Value Description PVID User can assign a Port VLAN ID for each port User can choose any port be “Tagged” or “Untagged”.

  • Page 44: Igmp Settings

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 the hosts in that traffic. This reduction of multicast traffic reduces the packet processing at the switch (at the cost of needing additional memory to handle the multicast tables) and also decreases the workload at the end hosts since their network cards (or operating system) will not receive and filter all the multicast traffic generated in the network.

  • Page 45: Igmp Snooping Status Table

    Traffic Prioritization includes three modes: port base, 802.1p/COS, and TOS/DSCP. By traffic prioritization function, users can classify the traffic into four classes for differential network application. All of Antaira’s industrial managed switches support four priority queues.

  • Page 46: Qos Classification

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.9.1 QoS Classification Figure 5.41 – QoS Classification Interface Terms Value Description Users can set it as “Weighted” or “Strict” Weighted mode: An 8, 4, 2, 1 weighting is applied to each round robin priority queue.

  • Page 47: Cos Mapping

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Users can set each port’s priority queue from 0 to 7 by Default Cost clicking from dropdown box; of which 0 is the Highest, and 7 is the Lowest Click “Apply” button to save changes.

  • Page 48: Tos Mapping

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.9.3 ToS Mapping ToS is an acronym for Type of Service. It is implemented as the IPv4 ToS priority control. It is fully decoded to determine the priority from the 6-bit ToS field in the IP header. The most significant 6 bits of the ToS field are fully decoded into 64 possibilities, and the singular code that results is compared against the corresponding bit in the IPv4 ToS priority control bit (0~63).

  • Page 49: Port Mirroring

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.10 Port Mirroring Enable or disable mirroring feature. When enabled, a copy of matched frames will be mirrored to the destination port specified in the port mirroring interface. Figure 5.47 – Port Mirroring Configuration Interface...

  • Page 50: Snmp

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.11 SNMP Simple Network Management Protocol (SNMP) is the protocol developed to manage nodes (servers, workstations, routers, switches and hubs etc.) on an IP network. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth.

  • Page 51: Snmp Trap Setting

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.11.2 SNMP Trap setting Figure 5.51 – SNMP Trap Setting Terms Value Description Enable SNMP Trap Enable SNMP Trap function by check the box User could insert the Server IP address as Trap...

  • Page 52: System Warning

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.12 System Warning System warning function is very important for managing a switch. Users can manage the switch by “Syslog”, “System Event Log”, and “Email Server” setup for Advanced Notice in any event type, “Event Type Selection”, and “Fault Alarm”...

  • Page 53: System Event Log

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 SYSLOG Server IP Address Insert remote SYSLOG server IP address Click “Apply” button to save changes. Figure 5.54 – SYSLOG Setting Terms & Value Description 5.12.2 System Event Log Users can view and display the system event log by clicking the “Apply” button on the right bottom corner of the interface.

  • Page 54: Smtp Setting

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.12.3 SMTP Setting The Simple Mail Transfer Protocol (SMTP) is for e-mail transmission across the Internet. Figure 5.56 – SMTP Setting Interface Terms Value Description E-mail Alert Enable/Disable transmission system warning events by e-mail.

  • Page 55: Event Selection

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.12.4 Event Selection Users can select any event type through the “Event Selection” interface, such as “System Cold Start”, any ports’ “Link Up”, “Link Down”, “Link Up & Link Down” and send the system warning massage to either SYSLOG or SMTP, or both at the same time.

  • Page 56: Mac Table

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.13 MAC Table The MAC address table is the filtering database that supports queries by the forwarding process, as to whether a frame received by a given port with a given destination MAC address is to be forwarded through a given potential transmission port.

  • Page 57: Maintenance

    Antaira is continuously developing new functions and features for specific application requirements for the industrial managed switches. Users can download the latest firmware from Antaira’s website and store it within their local PC, server, or USB drive. Figure 5.62 – Firmware Upgrade Interface...

  • Page 58: Reboot

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.14.2 Reboot Users can click the “Apply” button under the “Reboot” interface to reboot the switch. Figure 5.64 – Switch Reboot Interface 5.14.3 Default Users can reset the switch to “Factory Default” by clicking the “Apply” button under the default interface.

  • Page 59: Save

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 5.15.1 Save Users can click the “Save” button under the “SAVE CONFIGURATION” interface, once all the settings have been configured. Figure 5.66 – Save Setting Interface 5.15.2 Backup & Store Figure 5.67 – Backup & Restore Setting Interface...

  • Page 60: Auto Load & Backup

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 click the “Upload” the settings to the switch. USB Management Fill in the folder and filename and click the button of Save Running Config to USB Backup. If the folder or filename does not exist, system will generate it automatically.

  • Page 61: Command Line Interface Management

    6. Command Line Interface Management 6.1 About CLI Management Besides WEB-based management, LMP-0600 series also supports CLI management. Users can use console or telnet to manage the switch by CLI. CLI Management by RS-232 Serial Console (115200, 8, none, 1, none) Before configuring by an RS-232 serial console, use an RJ45 to DB9-F cable to connect the switches’...
  • Page 62 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Step 2: Input a name for the new connection. Step 3: Select to use a certain COM port number.
  • Page 63 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Step 4: The COM port properties settings should be as follows: 115200 for “Bits per second”, 8 for “Data bits”, none for “Parity”, 1 for “Stop bits” and none for “Flow control”.
  • Page 64 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 Follow the steps below to access the console via Telnet. Step 1: Telnet to the IP address of the switch from the Windows “Run” command as shown below. Step 2: The login screen will appear. Use the keyboard to enter the Username and Password, and then press “Enter”.
  • Page 65 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 show environment power 2 configure show environment temperature configure admin username admin configure admin password admin configure boot host dhcp configure ip address [ip_addr] [ip_mask] configure ip default-gateway [ip_router] configure ip name-server [ip_addr_string]...
  • Page 66 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 no ntp sync weekly configure show ntp client enable configure show ntp client timeserver configure show clock timezone configure show ntp sync schedule enable configure show ntp sync minute configure show ntp sync hour...
  • Page 67 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 vlan-mode [port | tag | qinq] configure vlan-group [group_num] [group_portlist] configure switchport pvid [vlan_id] interface switchport filter [tagged | untagged] interface switchport provider interface switchport ethertype [ether_type] interface no name vlan...
  • Page 68 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 timer wtr [time] g8032 no rpl [port0 | port1] g8032 no aps-channel g8032 no revertive g8032 no port0 g8032 no port1 g8032 no ring-id g8032 no timer hold-off g8032 no timer guard...
  • Page 69 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 spanning-tree forward-time [ forward time] configure spanning-tree hello-time [hello_time] configure spanning-tree max-age [max_age] configure spanning-tree cost [link_cost_value] interface spanning-tree port-priority [port_priority] interface spanning-tree link-type [point-to-point | point-to-multiple] interface spanning-tree auto-edge off...
  • Page 70 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 spanning-tree mst name [NAME] configure spanning-tree mst revision [REVISION] configure spanning-tree mst instance [instance_ID] vlan [vlan_grp] configure spanning-tree mst [instance_ID] priority [priority_number] configure spanning-tree mst [instance_ID] cost [cost_value] interface spanning-tree mst [instance_ID] port-priority [priority]...
  • Page 71 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 show event smtp authentication-failure configure show event smtp erps-change configure show event smtp interface [INTERFACE_NAME] [up | down] configure event syslog power1 enable configure event syslog power2 enable configure event syslog cold-start enable...
  • Page 72 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 syslog mode [both | remote | local] configure SYSLOG no syslog server configure no syslog mode configure show syslog server configure show syslog mode configure show syslog log configure smtp enable...
  • Page 73 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 snmp server v3 auth [admin | user] [md5 | sha] [PWD] configure snmp server v3 encryption [admin | user] [des | aes] [PWD] configure SNMP no snmp server enable configure no snmp server community [ro | rw]...
  • Page 74 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 show snmp trap host configure show snmp trap version configure show snmp trap community configure show snmp trap inform retry configure show snmp trap inform timeout configure show snmp trap v3 user...
  • Page 75 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 show qos default cos interface igmp snooping enable configure igmp snooping query max-respond-time [second] configure igmp snooping query interval [second] configure IGMP igmp snooping last-member count [time] configure igmp snooping last-member interval [second]...
  • Page 76 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 2. CLI : enable -> configure terminal ->copy startup-config usb (path) Fill in the folder and filename behind the “copy startup-config usb” command. Ex: file1, / folder /file2. 3. CLI :enable -> configure terminal ->copy usb startup-config (path) Fill in the folder and filename behind the “copy usb startup-config”...
  • Page 77 Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 4. CLI : enable -> configure terminal ->copy usb firmware (path) Fill in the folder and filename behind the “copy usb startup-config” command. Ex: file1, / folder /file2. CLI : enable -> configure terminal -> Syslog mode (usb or all) Select USB or ALL, it can auto save waning file to USB.

  • Page 78: Technical Specifications

    Antaira Industrial Ethernet Switches LMP-0600 Series User Manual V1.0 7. Technical Specifications Table 7.1, below, has the technical specifications for Antaira’s LMP-0600 series: 6-port industrial PoE+ managed Ethernet switch with 4*10/100Tx (30W/Port) RJ45 ports, and 2*10/100Tx RJ45 ports. IEEE 802.3 10Base-T 10Mbit/s Ethernet IEEE 802.3u...
  • Page 79 Antaira Customer Service and Support (Antaira US Headquarter) + 844-268-2472 (Antaira Europe Office) + 48-22-862-88-81 (Antaira Asia Office) + 886-2-2218-9733 Please report any problems to Antaira: www.antaira.com support@antaira.com www.antaira.eu info@antaira.eu www.antaira.com.tw info@antaira.com.tw Any changes to this material will be announced on the Antaira website.
