4.3 - Physical data BW10 units with hydronic module
BW10 (option 116J/270J)
Operating weight*
Height**
Hydronic module
Maximum operating pressure
Water filter (max. removed particle diameter)
Expansion tank capacity***
Water connections
*
Weight shown is a guideline only. .
**
The length and width dimensions are the same as for the standard unit.
*** When delivered, the standard pre-inflation of the tanks is not necessary the optimal value for the system. To permit changing the water volume, change the inflation pressure to
a pressure that is close to the static head of the system. Fill the system with water (purging the air) to a pressure value that is 10 to 20 kPa higher than the pressure in the tank.
4.4 - Electrical data BW10
BW10
Power circuit
Nominal voltage
Voltage range
Control circuit supply
Maximum start-up current draw (Un)*
Standard unit
Unit with electronic starter option
Unit power factor at maximum capacity**
Maximum operating power input**
Nominal unit operating current draw***
Maximum operating current draw (Un)****
Maximum operating current draw (Un-10%) †
Customer-side unit power reserve
Short-circuit stability and protection
*
Maximum instantaneous start-up current at operating limit values (maximum operating current of the smallest compressor(s) + fan current + locked rotor current of the largest
compressor).
**
Power input, compressors and fans, at the unit operating limits (saturated suction temperature 10°C, saturated condensing temperature 65°C) and nominal voltage of 400 V
(data given on the unit nameplate).
*** Standardised Eurovent conditions: evaporator entering/leaving water temperature 12°C/7°C, outside air temperature 35°C.
**** Maximum unit operating current at maximum unit power input and 400 V (values given on the unit nameplate).
†
Maximum unit operating current at maximum unit power input and 360 V.
4.5 - Short-circuit stability current (TN system*) - standard unit (with main disconnect switch)
BW10
Value without upstream protection
Short-term current at 1 s - Icw - kA rms
Admissible peak current - Ipk - kA pk
Value with upstream protection (circuit breaker)
Conditional short-circuit current Icc - kA rms
Schneider circuit breaker - Compact series
Reference number**
*
Earthing system type
**
If another current limitation protection system is used, its time-current and thermal constraint (I²t) trip characteristics must be at least equivalent to those of the recommended
Schneider circuit breaker. Contact your nearest Danfoss office.
The short-circuit stability current values above are in accordance with the TN system.
16
020
025
030
kg
305
313
313
mm
1463
1463
1463
kPa
300
300
300
mm
1.2
1.2
1.2
l
8
8
8
in
1.5
1.5
1.5
020
025
030
V-ph-Hz
400-3-50
V
360-440
24 V, via internal transformer
A
98
142
142
A
53.9
78.1
78.1
0.83
0.82
0.84
kW
9.7
11.4
12.7
A
10.5
13.2
13.8
A
16.1
19.6
21.1
A
19
22
24
Customer reserve at the 24 V control power circuit
See table below "Short-circuit stability current"
020
025
030
035
3
3
3
3
6
6
6
6
40
40
40
40
NSX 100N
LV429795
035
040
045
050
321
327
334
513
1463
1463
1463
1463
300
300
300
300
1.2
1.2
1.2
1.2
8
8
8
12
1.5
1.5
1.5
2
035
040
045
050
147
158
197
164
80.9
86.9
108.4
100.1
0.83
0.82
0.84
0.82
14.6
16.5
18.6
22.8
15.6
16.2
20.2
26.4
24.4
26.7
30.9
39.2
28
31
36
44
040
045
050
060
3
3
3
3
6
6
6
6
40
40
40
40
060
070
080
090
521
533
544
574
1463
1463
1463
1463
300
300
300
300
1.2
1.2
1.2
1.2
12
12
12
12
2
2
2
2
060
070
080
090
166
175
189
233
102.1
108.9
117.9
144.4
0.82
0.83
0.82
0.84
25.4
29.2
33
37.2
27.6
31.2
32.4
40.4
42.2
48.8
53.4
61.8
48
56
62
72
070
080
090
3
3
3
6
6
6
40
40
40
