TABLE Of CONTENTS Table of Contents ........................ 2 Important Safety Instructions ..................... 2 Safety Precautions ......................3 Identification of Controls ....................4 SETUP Menu Setting ......................7 SETUP Menu Introduction ....................9 Battery Parameters ......................10 Parameters and specifications ................... 11 IMPORTANT SAfETy INSTRUCTIONS Warning: To reduce the risk of electric shock, do not remove the cover or back.
SAfETy PRECAUTIONS Warning: This digital video disc player employs a laser system. Use of controls, adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation Exposure. Warning: To prevent direct exposure to laser beam,do not open the enclosure. Visible laser radiation when open.
IDENTIfICATION Of CONTROLS Main Unit DVD/DVB SOURCE VOL- / VOL+ ENTER next / right / prev / left / forward / up / backward / down / short press is up/right/down /left; long press is forward /next/backward/prev.
REMOTE CONTROL UNIT 1) PLAy/PAUSE Press PLAY/PAUSE once to pause playback, pressing PLAY/PAUSE second time will resume the playback. 2) STOP When this buttom is pressed once, the unit records the stopped point,from where playback will resume if ENTER is pressed after wards. But if STOP button is pressd again instead of ENTER button, there will be no resume function.
Page 6
15) DISPLAy To display the playtime and status information. 16) AUDIO Press AUDIO repeatedly during playback to hear a different audio language or audio track, if avilable. Press AUDIO repeatedly during playback to hear a different audio channel (Stereo, Left, or Right). 17) SUBTITLE Press SUBTITLE repeatedly during playback to hear a different subtitle languages.
SETUP MENU SETTING SySTEM SETUP PAGE Press SETUP button to get the setup menu. Use direction buttons to select the preferred item. After finishing settings, press to select the preferred item. After finishing settings, press SETUP again to normal display. •...
Page 8
AUDIO SETUP PAGE The function is usel to select the SPDIF output: SPDIF off, SPDIF/RAW,SPDIF/PCM. VIDEO SETUP PAGE You can change the video setting: brightness, contrast, hue, saturation. • Speaker Setup • Downmix: LT/RT: When playing a 5.1ch DVD disc, the LS/RS/Center channel audio will output through both L and R channel.
• Channel Guide TV Channels: Enter TV channels list. In TV channels list, press DISPLAY key can sort programs. Radio Channels: Enter radio channels list. In radio channels list, press DISPLAY key can sort programs. Channels Class: Set channels class: Favor, Movie, News, Show. Channels Edit: Edit channels: rename, move, delete.
• Game There are three games:BoxMan,Burning Tetris and Hit Rat.Select "ENTER" to play. EPG (ELECTRONIC PROGRAM GUIDE) The DVB-T player provides you an Electronic Program Guide to take a fast preview of live broadcasts from each TV channel in advance of watching it in full screen. 1) Press <EPG>...
2. Work circumstances Temperature Humidity Standard charge 0°C ~ +45°C 65 ± 20% Standard discharge -20°C ~ +65°C 65 ± 20% PARAMETERS AND SPECIfICATIONS ELECTRONICAL PARAMETERS Item Standard requirement Power requirements : AC 100 - 240 V, 50/60 Hz Dimensions : 250 (L) X 191 (W) X 42 (H) MM Power consumption : <...
