Summary of Contents for Coffee Queen Royal M6 x 20

  • Page 1: User Manual

    ”...WITH A PASSION FOR COFFEE” User manual COFFEE QUEEN Royal Your retail dealer U / EN Rev. 090914...
  • Page 2: Table Of Contents

    1. Table (list) of contents Royal Table of contents page. General Overview of the components, front. Overview of the components, mixer system. Overview of the components, chilled water Overview of the components, chilled water unit with carb. acid Installation and start 8-12 Place the machine Assemble machine...
  • Page 3: General

    2. General. Royal We congratulate to your choice of a Coffee Queen Freshbrew machine. Please read this manual before you take the machine into operation for the first time. The manual contains important instructions for a safe and proper use of the machine.
  • Page 4: Overview Of The Components, Front

    3. Overview of components, front Royal Display Strength of drinks ++ / - - Key switch 12 Drinks Door lock Outlet for drinks Water outlet cold drinks Cupholder Drip tray insert Drip tray Base cabinet with waste box and a water purifying screen.
  • Page 5: Overview Of The Components, Mixer System

    3. Overview of components, mixer system Royal Ingredients canister Bean container Chute Fuse holder Mixer bowls ON/OFF- switch Brewing mechanism Outlet chilled water/ carbonated water Waste box Outlet hot drinks Detail; Ingredients; Width; Height; Volume/litre; Amount/unit Canister; beans Canister; espresso Canister;...
  • Page 6: Overview Of The Components, Chilled Water

    3. Overview of components, water unit Royal Waste box Thermostat cooling unit Water IN Water OUT...
  • Page 7: Overview Of The Components, Chilled Water Unit With Carb. Acid

    3. Overview of components Royal , cold water unit + carbonic acid Waste box Gas holder Carbon dioxide tube Pump pressure, increase Thermostat...
  • Page 8: Installation And Start

    4. Installation and start. Royal Place the machine on a flat level and waterproof surface. Assemble top cabinet and base cabinet with the enclosed screws M6 x 20. M6 x 20 OBSERVE! Make sure there is a space behind the machine for free flow of air.
  • Page 9: Apply Carbon Dioxide Tube

    4. Installation and start. Royal Apply carbon dioxide tube. (See fig.2). Open the tap,Check the manufacturing pressure: 3.5bar. Adjustable:+ 0.5 -1.0 bar. Loosen screws and dismantle left side sheet. (see fig.2). Place carbon dioxide tube.(fig.3). Lift in waste box. (see fig.4) fig.2.
  • Page 10: Connecting Water To Machine

    4. Installation and start. Royal Connecting water to machine, (over cabinet). Connect attached water hose to cold water with an R 1/2”. Make sure that the water hose not are kinked anywhere when machine is pushed into place. Please flush the water hose before connecting to machine, this to avoid any particles to damage the inlet valve.
  • Page 11: Starting Up Machine

    4. Installation and start. Royal Starting up machine. 12. Connect the electric cable to the appliance plug. (B) Fig.3. (See fig3) 13. Turn ON the machine. Then wait until the text in display starts moving (forward). Push button for chilled water until water is coming in a even flow. This will make the pump more silent.
  • Page 12: Installation And Start

    4. Installation and start. Royal What happens when you push the buttons, for cold water and carbonated water functions? When you push the ”button” for carbonated water function, the inlet /outlet valves will start open at the same time. When you stop pushing the ”button” for carbonated water, the outlet valve will close and the inlet valve is open 20 seconds more.
  • Page 13: Operation; Brewing Of Coffee In Cup

    5. Operation: Brewing of coffee in cup. Royal Brewing of coffe. Chocolate etc. Place a cup in the centre of the cup holder. The strength has a standard setting, if you wish to increase or decrease it, do as follows if not continue to point 3.
  • Page 14: Brewing Of Jug

    5. Operation: Brewing of jug. Royal Brewing of jug. Lift up the cupholder. Place a jug in the centre of drip tray. Turn on the key with jug symbole clockwise. 6 cups of brewing is standard settings, Change amount of cups by pushing + or - button. Optional up to 12 cups or down to 1 cup brewing.
  • Page 15: Cooled Water In Cup Or A Bottle

    5. Operation. Cold water in cup or a bottle. Royal Excellense Cold water in cup or a bottle. ( with or without carbonated cold water ). Put a glass under the outlet for water (A) and push the button for chilled water or carbonated water.
  • Page 16 6. Cleaning program. Royal Weekly cleaning! Automatic cleaning of mixing bowls 2 or 3. If you only wish to clean the mixer bowl and whipper house; Follow these instructions: The mixer bowls can easily be cleaned with the key switch in ”cup”...
  • Page 17: Cleaning Program

    6. Cleaning program CLEANING: Royal Automatic cleaning of In/Outlet valves: The In/Outlet valves can easily be cleaned with the key switch in ”cup” (normal) position. Place a jug in the drip tray. Turn the key slowly ninety degrees and back again. Push button for drink 1 and 2 at the same time for 6 seconds.
  • Page 18: Rotate Brew Mechanism Without Water Or Ingredients

    6. Cleaning program CLEANING: Royal Rotate brew mechanism without water or ingredients: The brew mechanism can be rotatedwithout water and ingredients with the key switch in ”cup” (normal) position.To be used when brew mechanism has been dismounted forwashing and shall be remounted.
  • Page 19: Automatic Cleaning Of Brew Mechanism, Mixing Bowl

    6. Cleaning program CLEANING Royal Automatic cleaning of brew mechanism, mixing bowl: Shall been done every week. The brewmechanism can easily be cleaned with the key switch in ”cup” (normal) position. 1. Turn the key slowly ninety degress and back again. Fig.
  • Page 20: Dismantling Of Brew House

    6. Cleaning program CLEANING Royal Dismantling and cleaning brew house: Dismantle brew house: 3. Flush brew house! Reassemble brew house. NOTE! When reassemble brew house To remove detergent and coffee remnants. make sure that (B) wiper are between (A) arms. Important! wash carefully To remove cleaning...
  • Page 21: Weekly Cleaning

    7. CLEANING: Weekly cleaning Royal Dismantle : Mixer system Cleaning Loosen mixer bowl. Pull apart (C). 5. Clean with a wet rag and Loosen outlet hose (A) and drought drily. turn lock knob (B) anti-clockwise. Wash these parts: A. Mixer bowl B.
  • Page 22: Assemble Mixer System

    7. CLEANING: Weekly cleaning Royal REASSEMBLE: Mixer system Make sure that the motor whippers plane side will be in accordance with the whippers plane side. see next (G) and picture (H). Reassemble the assembly plate by turning lock knob (F) clockwise. INSPECT gaskets. pil (G).
  • Page 23 Prolonged contact with cleaning agent may damage the screen assembly. Once this is done, the screen should then be thoroughly rinsed with dish soap and warm water to remove any leftover residue. Cleaning agent: (brew mechanism) Coffee Queen article no 1104161 Filter: (brew mechanism) Coffee Queen article no 47200213 Tool: (dismantling filter)
  • Page 24: Cleaning And Maintenance

    8. Cleaning and maintenance Royal Cleaning when needed. Outside cleaning; use a soft rag and liquid cleaning agent to prevent scratches. Cleaning bean container. 1. Shut closing hatch. 2. Dismantle bean container. Use a soft rag and liquid cleaning agent to prevent scratches. Note! Make sure that all parts are dry before use.
  • Page 25: Cleaning Of Condenser - Changing Of Carbonic Tube

    8. Cleaning and maintenance Condenser Royal Condenser cleaning: Chiller unit. Must be cleaned every 6 month. With an extremily dusty environment you must have a frequently cleaning. 1.Open door 2. Loosen inspection 3. Remove inspection plate. (base cabinet) plate (2 screws) 4.
  • Page 26: Maintenance, Grinder

    8. Maintenance, Grinder. Royal Adjustments: The adjustment of the blades is set at the factory. All maintenance, adjustments and installations shall be done of an Coffee Queen authorized service technician. This coffee grinder is only constructed to grind coffee beans without additives (as tasted oils or sugar).
  • Page 27: Cup Counter And Easy Access

    9. Cup counter and Easy Access Royal Cup counter: The machine has a cup counter which is available to see and reset with the key switch in ”cup” (normal) position. Push ”-” button for 6 seconds. After 4 seconds the signal will go faster.. The display shows: ”Total xxx cups”...
  • Page 28: Safety Functions

    10. Safety functions. Royal The machine is equipped with following safety functions Indication of door Door not closed The display shows; ”Door open” ”Door open” When machine is not in use: Valves are blocked. 11. Failure messages. Failure messages which can mostly be corrected without any help from service company The display shows;...
  • Page 29: Installation Of Coin Mec

    15. Installation of coin mechanism. Installation of coin mechanism for freshbrew machines CQ. IMPORTANT: Installation must been done of an authorized technician. 1. Assemble coin mec and connect to display-card, placed inside door. (see fig. 10). (10) ( Connect with the enclosed fig.
  • Page 30: Dimension Sketch

    14. Dimension sketch Royal...
  • Page 31: Circuit Diagram

    15.Circuit diagram Royal...
  • Page 32 COFFEE QUEEN Royal FOR SERVICE Your retail dealer ................................................COFFEE QUEEN AB, Box 960, 671 29 ARVIKA, besöksadress; Korpralsv 1B, Tel vxl; +46 (0)570-47700, Fax; +46 (0)570-47719 E-mail: info@coffeequeen.se www.coffeequeen.se Art. nr/Art. no. 1704562...
