Model DV7001 User Guide
Super Audio CD/DVD Player

Advertisement

Table of Contents
loading

Related Manuals for Marantz DV7001

Summary of Contents for Marantz DV7001

  • Page 1 CLASS 1 LASER PRODUCT LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT Model DV7001 User Guide Super Audio CD/DVD Player...

  • Page 2: Copy Protection

    CONGRATULATIONS ON YOUR PURCHASE OF THIS FINE MARANTZ PRODUCT. MARANTZ is on the leading edge of DVD research for consumer products and this unit incorporates the latest technological developments. We are sure you will be fully satisfi ed with the DVD player.
  • Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifi...

  • Page 4: Disc Storage

    - The equipment shall be installed near the power supply so that the power supply is easily accessible. WARRANTY For warranty information, contact your local Marantz dis- trib u tor. RETAIN YOUR PURCHASE RECEIPT Your purchase receipt is your permanent record of a valua- ble purchase.

  • Page 5: Table Of Contents

    Table Of Contents 1 Before You Start Features...6 What’s in the box...7 Putting the batteries in the remote control ...7 Using the remote control ...7 Discs compatible with this player ...8 DVD-Video regions...9 General information ...9 MP3 compatibility information ...9 WMA compatibility information...9 JPEG compatibility information ...9 DivX compatibility information ...9...

  • Page 6: Before You Start

    CDs and DVDs. Superlative audio performance with Super Audio CD, DVD-Audio, Dolby* Digital and DTS* Logos: The DV7001 delivers breathtaking sound quality with Super Audio CD, DVD-Audio, Dolby Digital and DTS discs. DivX You can enjoy DivX recorded on DVD R/RW or CD-R/RW.

  • Page 7: What's In The Box

    Before You Start What’s in the box Thank you for buying this MARANTZ prod uct. Please confi rm that the following accessories are in the box when you open • Remote control • AAA/R03 dry cell batteries x2 • Audio/Video cable (yellow/red/white) •...

  • Page 8: Discs Compatible With This Player

    DivX fi les. *Some copy-controlled CDs may not conform to offi cial CD standards. They are special discs and may not play on the DV7001. *The DV7001 does not support the non-DVD side of a Dual Disc. Video CD compatibility: • Logo: •...

  • Page 9: Dvd-Video Regions

    Your DVD player also has a region mark, which you can fi nd on the rear panel. Discs from incompatible regions will not play in this player.

  • Page 10: Connecting Up

    Remote switch When using this DVD player independently, set this switch to INT. (INTERNAL). When using this DVD player in a system with a Marantz receiver equipped with a remote sensor, set the switch to EXT. (EXTERNAL). Change the switch setting using a pen with a sharp tip etc.

  • Page 11: Home Theater Video Connections

    Connecting Up Home theater video con nec tions This player outputs video in a number of different ways. Choose the one most suit able for your system using the guide below. If your TV has a component video input, we rec om mend using it to connect directly to the COM PO NENT VIDEO OUT of this player.

  • Page 12: Home Theater Audio Connections

    Connecting Up Home theater audio connections This player outputs multi-channel audio in digital form. Check the manual for your amplifi er/receiver to see what equipment it is com pat i ble with (especially which digital formats such as Dolby Digital, DTS, etc. It can decode).

  • Page 13: Controls & Displays

    Controls & Displays Front panel SUPER AUDIO CD/DVD PLAYER DV7001 STANDBY POWER ON/OFF STANDBY indicator • Lights when the unit is in standby. Disc tray • Place the disc here. 3 (PLAY) • Begins playing the disc play. 7 (STOP) •...

  • Page 14: Remote Control

    ANGLE – pages 24, 30 INPUT ( % / fi ) button – These buttons can switch between devices compatible with MARANTZ receivers. Refer to the receiver instruction manual for further details. • Applicable models: PM-1 1S1, PM-15S1, PM6001, PM7001, PM8001, SR9600.
  • Page 15 Controls & Displays Note • HDMI ON is set when the unit is shipped from the factory. • Set HDMI under the DVD Setup Menu to use HDMI functions (see pages 41, 42, 47). • This remote control supports two remote control codes: DVD1 and DVD2.

  • Page 16: Getting Started

    Getting Started Playing discs The basic playback controls for playing discs are cov ered here. Further func tions are detailed in the next chapter. Note • Throughout this manual, the term “DVD” means DVD-Video, and DVD R/RW. If a function is specifi c to a par tic u lar kind of DVD disc, it is specifi...

  • Page 17: Navigating Dvd Disc Menus

    Getting Started Navigating DVD disc menus Many DVD discs contain menus. Sometimes these are displayed automatically when you start playback; others only appear when you press MENU or TOP-M. Note • Some DVD-Audio discs feature a “Bonus Group”. To access this group you have to input a password that you can fi...

  • Page 18: Playing Discs

    Playing Discs Introduction • Many of the functions covered in this chapter apply to DVD discs, Video CDs and CDs, although the exact operation of some varies slightly with the kind of disc loaded. • When playing DVD discs, if the appears on-screen when you try to use a particular function, either the player or the disc doesn’t allow the use of that...
  • Page 19 Playing Discs • To go to the previous or next page, press 4 / ¢ . • Press ENTER on the selected thumbnail picture to start playback from there. • To return to the main menu, select MENU on the screen and press ENTER. To exit the preview menu, select EXIT on the screen and press ENTER.

  • Page 20: Fast Forward/Fast Reversed

    Playing Discs Fast Forward/Fast Reverse Super Audio CD Video-CD DivX The video images on DVD and VCD can be viewed as a Fast Forward and Fast Reverse with no sound. In case of CD, the sound can be listened as a Fast Forward and Fast Reverse with sound.

  • Page 21: Still Frame/Slow Play/Frame Advance Playback

    Playing Discs Still Frame/Slow Play/Frame Advance Playback DVD-Video Video-CD The video images on DVD and Video CD can be viewed as a still frame, played back at slow speeds and even advanced frame by frame (Forward only). Viewing a Paused Picture Press 8 (PAUSE).

  • Page 22: Using The Page

    Playing Discs Using the page DVD-Audio Some DVD-Audio discs contain information pages for photo galleries, artist biographies, lyrics, etc. Press the PAGE button on the remote control during Playback. You may select the image you want by moving the cursor button ( 2 / 3 ).

  • Page 23: Looping A Section Of A Disc

    Playing Discs Looping a section of a disc Super Audio CD Video-CD DivX Press A-B once at the start of the section you want to repeat, then again at the end. Playback immediately jumps back to the start point and plays the loop round and round.

  • Page 24: Switching Camera Angles

    Playing Discs Switching Camera Angles DVD-Video Some DVD-Video discs feature scenes shot from two or more angles. Check the disc box for details: it should be marked with a icon if it contains camera-angle scenes. • To switch the camera angle, press ANGLE. Note •...

  • Page 25: Switching The Audio Language

    Playing Discs Switching the Audio Language DVD-Video DVD-Audio When playing a DVD-Video disc recorded with dialog in two or more languages, you can switch the audio language at anytime during playback. • To display/switch the audio language, press AUDIO repeatedly. The current audio language is shown on-screen.

  • Page 26: Play Back Information

    Playing Discs Play back Information This DVD system can display the disc playback information (for example, title or chapter number, elapsed playing time, audio/subtitle language) and a number of operations can be done without interrupting disc playback. DVD-Video Video-CD During playback, press DISP. A list of available disc information appears •...

  • Page 27: Time Display

    Playing Discs Angle DVD-Video Press 5 / ∞ to highlight “Angle”, then press ENTER to access. Use the numeric keypad (0-9) to enter in a valid number. Press ENTER to confi rm. Playback will go to the selected angle. Time Display DVD-Video Video-CD Press 5 / ∞...
  • Page 28 Playing Discs Group/Track Selection and time search DVD-Audio Each time you press DISPLAY, the TV display changes as follows. GROUP 01/05 TRACK 01/15 0:10:00 GROUP 01/05 TRACK --/15 GROUP 01/05 TIME -/--/-- TRACK 01/15 TIME -/--/-- Press 5 / ∞ to select the Track, Group Time or Track time.

  • Page 29: Playing An Mp3/Divx/Jpeg/Windows Media Audio Disc

    Playing Discs Playing an MP3/DivX/JPEG/ ™ Windows Media Audio disc This DVD system can playback most of the MP3, JPEG and Windows Media ™ recorded on a CD-R/RW disc or commercial Insert a disc. The disc reading time may exceed 30 •...

  • Page 30: Playing A Jpeg Image Fi Le (Slide Show)

    Playing Discs Playing a JPEG image fi le (slide show) Insert a Picture disc (Kodak Picture CD, • JPEG). For a Kodak disc, the slide show will begin automatically. For a JPEG disc, the picture menu will appear on the TV.

  • Page 31: Playing Mp3/Wma Music And Jpeg Pictures Simultaneously

    Playing Discs Playing MP3/WMA music and JPEG pictures simultaneously You can create a musical slide show if the disc contains both the MP3/WMA music and JPEG picture fi les. Insert an MP3/WMA disc that contains music and pictures. Select an MP3/WMA track in the menu and press PLAY 3 to start playback.

  • Page 32: Playing A Divx Disc

    Playing Discs Playing a DivX disc This DVD system supports the playback of DivX movies which you can copy from your computer onto a CD-R/RW, DVD R/ RW disc (see page 9 for more information). Insert a DivX disc. Press PLAY to start playback.

  • Page 33: Using The Setup Menu

    Playing Discs Using the Setup Menu Before using the player, you should specify the settings to be used in accordance with the conditions under which the player is to be used. Note that once changed, the settings will be saved and remain the same even after the power has been turned off until the settings are changed again.

  • Page 34: Dvd Setup Menu

    • Press SET UP for longer than 2 sec to close the FL menu and then go back to standby mode. Note • The DVD player support two remote control codes: DVD 1 and DVD 2. • Set the remote control code of the Remote Control...
  • Page 35 DVD Setup Menu A black dot ( ) in di cates the default setting * It can be set only during STOP. OSD LANGUAGE PLAYER MODE DIVX(R) VOD CODE DISC LOCK * GENERAL DISPLAY DIM PROGRAM * SETUP SCREEN SAVER SLEEP AUTO STANDBY AUDIO OUT...

  • Page 36: Setting Up The General Setup Page

    DVD Setup Menu Setting up the GENERAL SETUP page Press the SETUP button. Select GENERAL SETUP PAGE using the cursor buttons ( 2 / 3 ), then press the ENTER button. Use the cursor buttons ( 5 / ∞ ) to select the desired item, then press the cursor ( 3 ) or ENTER button.
  • Page 37 DVD Setup Menu DivX(R) VOD CODE MARANTZ provides you with the DivX (Video On Demand) registration code that allows you to rent and purchase videos using VOD service. Press 3 to see the ® the DivX registration code and press ENTER to exit.
  • Page 38 DVD Setup Menu SCREEN SAVER • Default setting: ON The screen saver prevents damage to the TV screen by avoiding exposure to a static image for too long. • ON – Switches to TV screen saver mode when playback has been stopped or paused for more than 15 minutes.

  • Page 39: Setting Up The Audio Setup Page

    DVD Setup Menu Setting up the AUDIO SETUP page Press the SETUP button. Select AUDIO SETUP PAGE using the cursor buttons ( 2 / 3 ), then press the ENTER button. Use the cursor buttons ( 5 / ∞ ) to select the desired item, then press the cursor ( 3 ) or ENTER button.
  • Page 40 DVD Setup Menu About source audio output When the source output mode has been switched among 2CH, Virtual Surround and 5.1 CH mode setting using the Audio Out setting, audio output for each source will be as shown in the following table.
  • Page 41 • No digital audio is output when playing Super Audio CD. LPCM OUT • Default setting: 48kHz If you connect the DVD Player to a PCM compatible receiver via digital terminals, coaxial or optical, you may need to adjust “LPCM Output”. Discs are recorded at a certain sampling rate.
  • Page 42 DVD Setup Menu HDMI Audio Output Auto formats Dolby Digital Linear PCM Multi channel PCM DVD-Audio Multi channel PCM CD/MP3/Super Audio CD* DTS CD Video CD : The order of priority in Auto mode is: Bit Stream, Multi PCM, 2ch PCM. The output format is limited by the ca pa bil i ties of the connected component.

  • Page 43: Audio Drc

    DVD Setup Menu SPEAKER DISTANCE Delay time settings in relation to the listening position/distance for individual speakers (1.0 MS to 9.0 MS). SPEAKERS DISTANCE SETUP FRONT LEFT 3.0M FRONT RIGHT 3.0M CENTER 3.0M 3.0M REAR LEFT 3.0M REAR RIGHT 3.0M Note •...

  • Page 44: Setting Up The Video Setup Page

    DVD Setup Menu Setting up the VIDEO SETUP page Press the SETUP button. Select VIDEO SETUP PAGE using the cursor buttons ( 2 / 3 ), then press the ENTER button. Use the cursor buttons ( 5 / ∞ ) to select the desired item, then press the cursor ( 3 ) or ENTER button.

  • Page 45: Home Theater Video Connections 1

    DVD Setup Menu CHANGING PAL TO NTSC 1.ENSURE THAT YOUR TV SYSTEM SUPPORTS NTSC STANDARD. 2.IF THERE IS A DISTORTED PICTURE DISPLAYED ON THE TV.WAIT IS SECONDS FOR AUTO RECOVER CANCEL Video output format when progressive is "ON". Disc Output Format Format system YCbCr...
  • Page 46 DVD Setup Menu ! Press 2 to highlight OK in the menu and press ENTER to confi rm. The set-up is complete now and you can start to enjoy the high quality picture. • OFF – Disables the progressive scan mode.
  • Page 47 DVD Setup Menu HDMI VIDEO • Default setting: AUTO Selects a suitable video resolution depending on the capability of the connected TV/device to enhance the HDMI video output. • 480P – Progressive output in 480 lines for NTSC TV • 576P – Progressive output in 576 lines for PAL TV •...
  • Page 48 DVD Setup Menu Setup Examples Video Disc S-Video TV Aspect YCbCr Format (Progressive:OFF) 16:9 Wide 16:9 4:3 LB 4:3 PS* 4:3 PS* 16:9 Wide 4:3 LB 4:3 PS : When actual video output is Pan-scan. ("TV Aspect" is 4:3panscan and disc permits Pan-scan.) : When actual video output is Letterbox.
  • Page 49 DVD Setup Menu DYNAMIC PICTURE Produces more dynamic picture by increasing the picture contrast and the color intensity. This function is available only for progressive scan output. 0 to 5 DVI OUTPUT RANGE • Default setting: STANDARD When connecting the DVI unit, black may rise to the surface depending on the display.

  • Page 50: Setting Up The Preference Page

    DVD Setup Menu Setting up the PREFERENCE page Press 7 (STOP) twice to stop playback (if any), then press SETUP. Select PREFERENCE PAGE using the cursor buttons ( 2 / 3 ), then press the ENTER button. Use the cursor buttons ( 5 / ∞ ) to select the desired item, then press the cursor ( 3 ) or ENTER button.
  • Page 51 DVD Setup Menu DISC MENU Selects the preferred disc menu language for DVD playback. • Default setting: ENGLISH Use the 5 / ∞ keys to select a language and press ENTER to confi rm. Note • For some discs, selection can be made using the DVD menu.
  • Page 52 DVD Setup Menu Previewing VR format During playback, press SCAN. Press 5 / ∞ to highlight either TITLE DIGEST or TITLE INTERVAL. SELECT DIGEST TYPE TITLE DIGEST CHAPTER DIGEST TITLE INTERVAL CHAPTER INTERVAL Press ENTER to select the function. • TITLE DIGEST – This function will display thumbnail pictures of titles on the screen.
  • Page 53 DVD Setup Menu DEFAULT This feature enables you to reset all the setup menu options and your personal settings to the factory defaults, except your password for Parental Control and Disc Lock. Press ENTER to confi rm the default reset.

  • Page 54: Additional Information

    Additional Information Language Codes This page is used to select other languages. This does not affect the options in AUDIO, SUBTITLE or DISC MENU. Abkhazian 6566 Afar 6565 Afrikaans 6570 Albanian 8381 Amharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Avestan 6569 Aymara...

  • Page 55: Handling Discs

    The DVD player’s lens should not become dirty in normal use, but if for some reason it should mal func tion due to dust or dirt, consult your nearest MARANTZ-authorized service center. Al though lens cleaners for CD players are com mer cial ly available, we do not recommend using them since some may damage the lens.

  • Page 56: Hints On Installation

    A damaged power cord can cause a fi re or give you an electric shock. Check the power cord once in a while. If you fi nd it damaged, ask your nearest MARANTZ authorized service center or your dealer for a re place ment.

  • Page 57: Troubleshooting

    If the trouble cannot be rectifi ed after checking the items below, ask your nearest MARANTZ authorized service center or your dealer to carry out repair work. The disc is ejected automatically after loading.
  • Page 58 Additional Information The remote control doesn't seem to work. • The remote control is too far from the player, or the angle with the remote sensor is too wide. Use the remote control within its operating range (page • The batteries are exhausted. Put in new batteries (page 7).
  • Page 59 Theater's mode with DivX” certifi ed encoder. No sound during DivX movies playback. • The audio codes may not be supported by the DVD player. A DivX movie does not repeat. • Check that fi le size of the movies does not exceed the fi le...

  • Page 60: Specifi Cations

    Additional Information Specifi cations General System DVD-Video, DVD-Audio, DVD R/RW, Super Audio CD, Video CD, CD, MP3 fi les, JPEG fi les, DivX and Power requirements (U.S.A.)... 120 V, 60Hz Power requirements (Europe) ...230 V, 50/60Hz Power consumption... 27 W Power consumption in standby mode...0.8 W Weight...
