Partner: Marantz
Model: DV7600
Device Type: DVD Player
GENERAL INFORMATION
SIMPLWINDOWS NAME:
CATEGORY:
VERSION:
SUMMARY:
GENERAL NOTES:
CRESTRON HARDWARE REQUIRED:
SETUP OF CRESTRON HARDWARE:
VENDOR FIRMWARE:
VENDOR SETUP:
CABLE DIAGRAM:
Marantz DV7600
Transport Decks
1.0
Controls the Marantz DV7600 DVD player and provides true feedback
This module provides all controls for the Marantz DV7600 DVD player. It also
provides true feedback. There are three layers of feedback. It is possible turn on and
off any combination of these layers. This module provides commands to do this.
NOTE: THE DV7600 SHIPS FROM THE FACTORY WITH ECONOMY MODE ENABLED. IF
YOU DO NOT DISABLE ECONOMY MODE, YOU WILL NOT BE ABLE TO TURN THE
DV7600 ON USING RS232.
CNX-COM, C2-COM, ST-COM
RS232
Baud: 9600
Parity: None
Data Bits: 8
Stop Bits: 1
RS-232C Ver: 1.01
BE Ver: MZD70084/NTSC
Panel ucom Ver: H50507
YOU MUST DISABLE THE ECONOMY MODE.
CNSP-123

Advertisement

loading
Need help?

Need help?

Do you have a question about the DV7600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marantz DV7600

Summary of Contents for Marantz DV7600

  • Page 1 Transport Decks Controls the Marantz DV7600 DVD player and provides true feedback This module provides all controls for the Marantz DV7600 DVD player. It also provides true feedback. There are three layers of feedback. It is possible turn on and off any combination of these layers.
  • Page 2 Audio Front_Disp_* Serial signal to be routed from a 2-way serial com port. Pulse to turn the DV7600 on and off. The DV7600 will NOT turn on if the Economy Mode is ENABLED. Pulse to open and close the tray.
  • Page 3 Partner: Marantz Model: DV7600 Device Type: DVD Player Num* Up/Down/Left/Right/Enter/return/clear Sacd_mode Tv_system Progressive/interlace Aspect_* Video_mute_on/off/toggle Video_adj Zoom Hdmi* Condition_memo Autopoweroff_* IR_code* Auto_status_mode* Pulse to enter track or chapter numbers. The num+10 is need for tracks or chapters above 9. Pulse the num+10 once for 10 to 19, twice for 20 to 29.
  • Page 4 Partner: Marantz Model: DV7600 Device Type: DVD Player FEEDBACK: To_Device$ Power_on/stby_fb Tray_open/close_fb Toc_fb Play/stop/pause_fb Fast_search+/-_fb Slow_search+/-_fb Disc_*_fb Repeat_off/1/all_fb Repeat_a-b_off/a-set/a-b_set_fb Random_off/on_fb Time$ Track_ana Chapter_ana Title_ana Group_ana Front_disp_off/dim/on_fb Sacd_*_fb Tv_sys_*_fb Progressive/interlaced_fb Aspect_*_fb Serial signal to be routed to a 2-way serial com port.

  • Page 5: Sample Program

    High to indicate the current state of the autopower off function. LAYER 2 FEEDBACK. High to indicate the current IR code state. LAYER 2 FEEDBACK. High to indicate the level of automatic feedback. PRO2: 3.137 CNMSX-Pro: 5.14.02 2.06.20 Marantz DV7600 Demo V. 1.0...
