unit controls

1. On/Off Button ( )
Press and hold this button for 2 seconds
to turn your unit on or off. You may also
pause the exercise by briefly pressing this
button.
2. Increase Toning Intensity (
Press and hold these buttons to increase
the intensity of the exercise. The right-
hand button controls the right-hand side
of your belt. The left-hand button controls
the left-hand side.
3. Decrease Toning Intensity (
Press and hold these buttons to decrease the
intensity of the exercise on either side of the belt.
4. Programme Button ( P )
Press this button to select the toning programme you
wish to use. There are 7 programmes in total, which are explained later in
this manual (page 8).
5. Information Button ( i )
Press this button to see your training information, such as the maximum
intensity for your current or last session and the number of sessions you
have completed.

unit display

Toning intensity from the left-hand side of the belt.
Toning intensity from the right-hand side of the belt.
Counts down the time left in the current session. Also displays error
messages (see page 10).
Appears when the exercise has been paused.
Indicates that the sound is off.
Keylock is active - you cannot change the intensity levels or the
program accidentally.
This symbol indicates a poor contact between the unit and the belt
or between the pads and the skin (see page 14 for more details).
Shows the battery power remaining.
Number of sessions completed.
Shows the programme currently running (1 - 7).
This symbol appears during each contraction phase.
Maximum intensity for the current/ last session.
4
unit display
)
1.
2.
3.
)

how does muscle stimulation technology work?

-
SLENDERTONE SYSTEM ABS
This technology has been used in hospitals and by physiotherapists for over
50 years. Here is a summary of how EMS technology works.
patented 3-pad design ensures that all of the abdominal muscles contract
and not only those directly under the pads.
4.
5.
Step 1
Signals are sent
between the pads

setting up your slendertone system-abs

Step 1 - Charge the battery. Insert your charger into a
socket and then connect it to your unit (Fig. a). It'll take
approximately 3 hours to fully charge the battery. Your
unit is fully charged when all three sections of the battery
icon are full. The battery icon will flash when the battery
is low and needs to be recharged.
: Please ensure you only use the
NOTE
Charger when charging your control unit. Do not leave
your unit connected to the charger when the battery is
fully charged.
Step 2 - Connect the unit to the belt. The unit and belt
must be connected for your
work. 'Click' the unit connector into the belt connector
as shown in Fig. b.
Step 3 - Place the pads on the belt. Turn the belt over so
that the 3 silver studs are facing upwards. Remove the
three adhesive pads from their pack. There is 1 large
square pad and 2 smaller oval pads. One side of each
pad has a grid pattern on it while the other side is plain
black.
(i) Remove the covers from the patterned side of the
large pad (Fig. c).
(ii) Place the patterned side of this pad over the middle
stud and between the white lines.
(iii) Now remove the covers from the patterned side of the two smaller pads
and place them either side of the large pad (Fig. d).
uses electrical muscle stimulation (EMS) technology.
Step 2
The signals switch on the The nerves, in turn, cause
nerves which control the
abdominal muscles.
SLENDERTONE SYSTEM
- to
SLENDERTONE SYSTEM ABS
's
SLENDERTONE
Step 3
your muscles to contract
and relax rhythmically.
Fig. a
Fig. b
Fig. c
Fig. d
5
